Power and Control Connections
DC 9V (Power)
Connect to the included 9 Volt DC power supply. If you would like to use a 3
power supply must be regulated at 9 Volts DC (direct current), able to source at least 300 mA
(milliamps) of current, and the plug should have a tip-negative, barrel-positive polarity.
USB
Connect to your computer (Mac or Windows) to the Collider's USB port (denoted by the icon) using a
standard mini USB cable. The Collider is a class compliant USB device, meaning that it does not
require any custom drivers. For more information about the Collider's USB capabilities, refer to the
of the User's Guide.
USB Section
Control Input
The 3.5 mm C
ONTROL
Tempo Switch, Source Audio Dual Expression Pedal, Neuro Hub, and Hot Hand Motion Controller. For
more information, refer to the
the User's Guide.
Expression/Switch Pedal Input
The P I jack on the back panel connects to either an external passive expression pedal or
EDAL N
footswitch. The P
EDAL
used. Set to EXP for expression control or SWITCH for footswitch control. See the
section for details.
SA263
I port connects to external control devices such as the Source Audio Tap
NPUT
Expression Pedal
I S allows the user to select which type of external controller is being
N WITCH
Collider Delay+Reverb Owner's Manual
Input, Hot Hand Input, and
-party supply, the
rd
Neuro Hub sections of
External Control
