hand line for line. An example of such a program is shown at the left.
The procedure for creating such a program is described in detail in the
Chapter "First Steps". The ROBO Pro Help feature also shows how this
works in Chapters 3 and 4.
This software has already been installed on your PC together with this
activity booklet.

ROBOTICS TXT Controller

The ROBOTICS TXT Controller is the heart of this ROBOTICS
construction set. It controls actuators, and evaluates the information
from the sensors.
For this purpose the ROBOTICS TXT Controller has numerous terminals
for connection to the components. The instruction manual for the
ROBOTICS TXT Controller describes which components can be
connected to which connections and the functions of the connections.
The color touch screen allows convenient operation of your ROBOTICS
TXT Controller. The camera contained in the construction set can be
connected to the USB host port (USB-1). The integrated Bluetooth and
WLAN interface is a particularly interesting special feature. It allows you
to complete a wireless link between your PC and the ROBOTICS TXT
Controller.
You can define how the controller interacts with the individual
components and what they are to do in detail in the program you write
with the ROBO Pro software.
Power Supply (not included)
As you know, many of the components in the ROBOTICS TXT Discovery
Set need electricity to operate, so naturally you also need a power
supply.
The fischertechnik Accu Set is best suited for this. It is not included in
the construction set.
