BEST ACCESS SYSTEMS 9KQ Installation Instructions Manual

Planning the installation
Contents
These installation instructions describe how to install your
93KQ Cylindrical Lock. Topics covered include:
Planning the installation
Preparing the door and door jamb
Installing the lock
........................................................... 7
Completing the installation
Patents
Products covered by one or more of the following patents:
5,590,555 5,794,472 5,083,122 6,720,861
Site survey
Use the following survey to record information about the
installation site. You need this information to determine
how to prepare the door for the lock.
Door information
Door handing and bevel:
Left hand (LH)
❑
❑ Left hand, reverse bevel (LHRB)
Right hand (RH)
❑
Right hand, reverse bevel (RHRB)
❑
inches (1 3/4" to 2 1/4" )
Door thickness:
Environment information
Ambient temperature:
Is within specifications. See the tables below.
❑
This product meets the following Locked Door Outdoor
test requirements for ANSI/BHMA 156.25:
Side of door Range
Outside –31°F to +151°F (–35°C
to +66°C)
This product meets the following Full Indoor test require-
ments for ANSI/BHMA 156.25:
Side of door Range
Inside and out- +32°F to +120°F (0°C to +49°C)
side
Installation Instructions for
Wi-Q™ Technology 9KQ Cylindrical Locks
............................................... 1
.............................. 2
........................................13
BEST ACCESS SYSTEMS
a Product Group of dormakaba USA Inc.
Components checklist
Use the following checklist to make sure that you have the
items necessary to install your Electronic Wireless Cylin-
drical Lock.
Components provided in the box:
Chassis with outside lever and outside rose liner
❑
assembly
Top and bottom inside covers
❑
Fire plate
❑
Battery holder with batteries
❑
Inside rose liner
❑
Outside escutcheon assembly
❑
❑ Inside lever
Throw member package
❑
Latch
❑
Hub washers
❑
Trim hole insert package
❑
❑ Plastic bushing package
❑ Escutcheon screw package
Door status switch assembly
❑
Strike package
❑
Bar code ID sticker (for your records)
❑
Installation template and instructions
❑
Other components:
Core and control key
❑
❑ Temporary operator card
Special tools checklist
Use the following checklist to make sure that you have the
special tools necessary to install your Electronic Wireless
Cylindrical Lock.
KD303 Drill jig
❑
T20 TORX® bit driver
❑
❑ KD325 Strike plate locating pin
KD315 Faceplate marking chisel
❑
1
