BEST ACCESS SYSTEMS 45HQ Installation Instructions Manual

Contents
These installation instructions describe how to install your
45HQ Mortise Lock. Topics covered include:
Preparing the door
........................................................ 1
Configuring and installing the mortise case
Installing the trim
.......................................................... 4
Completing the installation
Patents
Products covered by one or more of the following patents:
6,720,861
1
Identify holes to drill
1 Determine the lock function to be installed.
Caution: Determine the inside and outside, hand, and
bevel of the door.
2 See the Holes by Function
determine the holes to be drilled for the lock function.
Holes by Function
Holes to drill
A Forged trim
†
(2 holes)
†
B Harness
C Standard cylinder
D Sensor & motor wire
(2 holes)
F Thumb turn
G Trim mounting
‡
(2 holes)
††
H Lever
J Door sensing channel
(2 holes)
† Determine trim holes based on trim type.
‡ Because these holes pass through the mortise pocket,
it is recommended that each hole be drilled separately
rather than straight through.
Installation Instructions for
Wi-Q™ Technology 45HQ Mortise Locks
.............. 3
.......................................... 9
table and Figure 1 to
Functions
DV TV
I/S O/S I/S O/S
Through Through
door door
Through Through
door door
■
■
■ ■
■
Through Through
door door
Through Through
door door
DO NOT See Figure
DRILL 1
BEST ACCESS SYSTEMS
a Product Group of Stanley Security Solutions, Inc
B
For hole sizes, see the
Q06 Template
(T82606).
D
Figure 1 Identifying holes to drill
J
J
J
A
B
C
F
G
H
G
D
A
