Tecomec COMPACT Owner's Manual page 108

Compact 230V~ - Spare Parts
P/N DESCRIPTION
K00200203
1 Complete vise assembly
K00200356
2 Chain hold kit
K00200352
3 Spring
K00200193
4 Chain stop, vise assy
K00200350
5 Chain stop
K00200351
6 Spring
K00200197
7 vise handle
K00200199
8 cam post
K00200357
9 Adjustment knobs, kit
K00200196
10 vise jaws
K00200353
11 chain vise spacers
K00200180
12 Spring
K00200342
13 Vise locking kit
K00200333
14 Scales Kit
K00200145
Cable kit complete with plug - 120V~
15
K00200160
Cable kit complete with plug - 230V~
K00200161
Cable kit complete with plug-230V~ CH
K00200162
Cable kit complete with plug-230V~ AUS
K00200155
16 End motor bell
K00200152
17 Capacitor 8 Micro-Farad - 120V~
K00200158 Capacitor 8 Micro-Farad - 230V~
18 K00200147
Handle kit
19 K00200355 Motor flange kit ( outer and inner)
K00200151
20 Switch - 120V~
K00200157 Switch - 230V~
K00200201
21 Spring, arm return
22 K00200184 Bracket, arm support
K00200195
24 Shield wheel protector
25 K00200140 Shield kit
K00200144
26 E-Motor - 120V~
K00200159
E-Motor - 230V~
106 106
COPACT _07/2011
15
16
26
18
1
9
7
4
6
5
11
10
230V~ 50Hz
17
19
8
3
12
2
9
20
21
13
22
25
24
14
