Functional Description and Specifications

Disconnect the plug from the power source before making any
!
WARNING
assembly, adjustments or changing accessories. Such preventive safety
measures reduce the risk of starting the tool accidentally.
VENTILATION OPENINGS
LOCKING SLEEVE
DUST SHIELD
NOTE: For tool specifications refer to the nameplate on your tool.
Rotary Hammer
SELECTOR LEVER
AUXILIARY
HANDLE
HAND GRIP
Model number
Shank style
Maximum Capacities:
Carbide tipped bits
Thin wall core bits
FIG. 1
VENTILATION
OPENINGS
11263EVS
SDS Max
1-3/4"
5"
-6-
TRIGGER
SWITCH
TRIGGER
RELEASE
SWITCH
VARIABLE
SPEED DIAL
SERVICE
REMINDER
LIGHT
