Appendix C Numbering interfaces

Numbering interfaces

Interfaces on the L1000-A are numbered in the form of interface-type X/Y, where,
• interface-type represents the type of the interface such as GigabitEthernet.
X represents the number of the slot where the interface module resides.
•
Y represents the sequence number of the interface on the interface module.
•
Note the following:
Interfaces on the same interface module have the same slot number X.
•
For each type of interfaces, the sequence number Y starts from 0 and increases according to the
•
sequence on the interface module (from left to right).

Examples

1. The fixed fiber/copper ports on the front panel of the F1000-A-EI are numbered as follows:
GigabitEthernet 0/0
GigabitEthernet 0/1
GigabitEthernet 0/2
GigabitEthernet 0/3
GigabitEthernet 0/4
GigabitEthernet 0/5
GigabitEthernet 0/6
GigabitEthernet 0/7
GigabitEthernet 0/8
GigabitEthernet 0/9
GigabitEthernet 0/10
GigabitEthernet 0/1 1
2. If both slot 1 and slot 2 of the L1000-A are installed with an NSQ1GP4U0, the GigabitEthernet
interfaces are numbered as follows:
Slot 1—GigabitEthernet 1/0, GigabitEthernet 1/1, GigabitEthernet 1/2, GigabitEthernet
1/3.
Slot 2—GigabitEthernet 2/0, GigabitEthernet 2/1, GigabitEthernet 2/2, GigabitEthernet
2/3.
