10.10 WF5A Pin Injection

Standard
Voltage
Current
Impedance
Current
Risetime
Duration
Voltage
Risetime
Duration
Syncro
EUT
max. Voltage
max. Frequency
Coupling Device

10.11 WF5A Cable Induction

Standard
Level
Single Stroke
Multiple Stroke
Current
Risetime
Duration
Voltage
Risetime
Duration
Coupling Device
DO-160 Section 22
50V - 500V +10% / -0%
50A - 500A +10% / -0%
1Ohm
40us 20%
120us 20%
40us 20%
120us 20%
90 10
270 10
230V
800Hz
direct
DO-160 Section 22
MIL-STD-461G CS117
30A - 1800A
30A - 1800A
20A - 390A
40us 20%
120us 20%
6.4us to 40us
>6.4us
CN-BT7
10 Technical Data
positive Pulse
negative Pulse
First Stroke
Subsequent Strokes
