5 Emergency stop button
Push to open the safety circuit.
As soon as the safety circuit is open, all running tests are immediately stopped and no more tests
can be started.
Release the emergency stop button with a slight turn clockwise.
A closed safety circuit is indicated by a red illuminated emergency stop button.
6 USB Port
Connect a USB memory stick to copy files (setups, protocols, error logs) from the generator. The
USB interface is also used to update the internal firmware.
7 Auxiliary Connection
Interface for additional external equipment.
8 Trigger out
BNC output for a direct connection to the scope to start pulse acquisition. Level and duration
depend on the specific test. Some typical values are
12V primary impulse trigger
8V secondary impulse trigger
5V EUT power state
9 Plug-in module
The plug-in contains all WF3 circuits. It is part of the AVI3000 standard delivery. Future plug-ins
could be developed for different wave forms. The plug-ins are secured by two retained screws on
the bottom.
Never remove a plug-in during a running test.
