StarTech.com PEX2S953 Quick Start Manual page 2

6. Repeat these steps to configure the Jumpers for Port 2.
Notes: The Jumper for Port 2 is labeled as J7 on the Printed Circuit Board.
Jumper
Reconfigure the PCI Express Serial Card for Low-Profile installations
1. Remove the four Stand-offs by twisting each one counterclockwise, using Needle-
Nose Pliers.
2. Remove the Bracket.
3. Slide the Low-Profile Brackets over the Serial Ports.
4. Insert two Stand-offs through each Bracket and tighten by twisting each one
clockwise, using Needle-Nose Pliers.
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation. Changes or modifications not expressly approved by StarTech.com could void
the user's authority to operate the equipment.
Industry Canada Statement
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.
CAN ICES-3 (B)/NMB-3(B)
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:
(1) This device may not cause interference, and (2) This device must accept any interference, including interference that may
cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation
est autorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d'en compromettre le fonctionnement.
IC Radiation Exposure Statement
This equipment complies with IC RSS-102 radiation exposure limit set forth for an uncontrolled environment. This equipment
should be installed and operated with minimum distance 0.5cm between the radiator and your body.
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-
party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only
and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which
this manual applies by the third-party company in question. StarTech.com hereby acknowledges that all trademarks, registered
trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the
property of their respective holders.
Figure 1
Hardware Installation
1. Ensure the Computer's Power is Off.
2. Unplug the Computer's Power Cord.
3. Remove the Computer's Cover.
Note: For further information on how to remove the Computer's Cover, refer to
the Manual that came with the Computer.
4. Remove the Slot Bracket's Holding Screw.
5. Remove the corresponding Full-Height Bracket from an available PCIe Slot.
6. To install the PCI Express Serial Card, carefully align the PCI Express Serial Card's
Bus Connector with the selected PCIe Slot on the Motherboard. Push the PCI
Express Serial Card down firmly to ensure the Card is properly seated into the PCIe
Slot.
7. (Optional - for power output from the ninth pin of the Serial Connectors) Connect
the LP4 Power Connector Cable from the Computer's Power Supply to the LP4
Power Connector Port on the PCI Express Serial Card.
8. Replace the Slot Bracket's Holding Screw to secure the PCI Express Serial Card.
9. Replace the Computer's Cover and reconnect the Power Cord.
10. Download the latest Drivers.
Driver Installation
You can download the latest Drivers from the StarTech.com website:
www.startech.com/PEX2S953.
Navigate to the Support Page to locate the Drivers. Follow the instructions included
with the Driver Files.
Warranty Information
This product is backed by a lifetime warranty.
For further information on product warranty terms and conditions, please refer to www.startech.com/warranty.
