Setup Guide
Read this first.
This describes the setup tasks and important conditions about the instal-
lation location that must be met in order to enable use of this machine.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FLATJET Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Roland FLATJET Series

Summary of Contents for Roland FLATJET Series

  • Page 1 Setup Guide Read this first. This describes the setup tasks and important conditions about the instal- lation location that must be met in order to enable use of this machine.
  • Page 2 The operation manual and the product have been prepared and tested as much as possible. If you find any misprint or error, please inform us. Roland DG Corp. assumes no responsibility for any direct or indirect loss or damage which may occur through use of this product, regardless of any failure to perform on the part of this product.

  • Page 3: Table Of Contents

    Remove the Packing Materials From the Base Section ..............32 7. Matching the Machine to the Environment Where Installed ................ 34 Company names and product names are trademarks or registered trademarks of their respective holders. http://www.rolanddg.com/ Copyright© 2004 Roland DG Corporation...

  • Page 5: To Ensure Safe Use

    To Ensure Safe Use...
  • Page 6 To Ensure Safe Use Improper handling or operation of this machine may result in injury or damage to property. Points which must be observed to prevent such injury or damage are described as follows. About WARNING and CAUTION Notices Used for instructions intended to alert the user to the risk of death or severe WARNING injury should the unit be used improperly.
  • Page 7 To Ensure Safe Use Moving the machine requires special equipment and training WARNING Do not emplace or move the machine yourself. The machine weighs approximately 500 kg (1103 lb.), and moving it requires special equipment and training. Performing operations in an unrea- sonable manner may result in a major accident.
  • Page 8 Roland DG Corp. service center. Never place any object on the power cord, bend the power cord using excessive force, or allow the power cord to become de- formed.
  • Page 9 To Ensure Safe Use Ink, cleaning liquid, and discharged fluid are flammable and toxic WARNING CAUTION Never operate in locations such as those Ensure adequate ventilation for the work near an open flame or heater, or where area. sparking or static electricity may occur. Odor from ink and the like may cause physical Ink or the like may ignite and cause fire.
  • Page 10 To Ensure Safe Use Important Notes Regarding Operators and the Work Area WARNING CAUTION Never operate the machine when tired or Never attempt operation while wearing a after ingesting alcohol or medications. necktie, necklace, loose clothing, or the Operation requires appropriate judgment, and like.
  • Page 11 To Ensure Safe Use Warning Labels Warning labels are affixed to make areas of danger immediately clear. The meanings of these labels are as follows. Be sure to heed their warnings. Also, never remove the labels or allow them to become obscured. Flammable Ink and discharged fluid are flammable.
  • Page 12 To Ensure Safe Use Caution: Pinching Hazard Moves while printing. Be careful not to get your fingers or hand caught in between the machine parts. Caution: Pinching Caution: Pinching Hazard Hazard Moves while printing. Be careful not to Moves while get your fingers or hand caught in printing.

  • Page 13: Pour Utiliser En Toute Sécurité

    Pour utiliser en toute sécurité...
  • Page 14 Pour utiliser en toute sécurité La manipulation ou l'utilisation inadéquates de cet appareil peuvent causer des blessures ou des dommages matériels. Les précautions à prendre pour prévenir les blessures ou les dommages sont décrites ci-dessous. Avis sur les avertissements Utilisé pour avertir l'utilisateur d'un risque de décès ou de blessure grave en cas ATTENTION de mauvaise utilisation de l'appareil.
  • Page 15 Pour utiliser en toute sécurité Le déplacement de l’appareil requiert un matériel et un savoir-faire spécialisés. ATTENTION Ne jamais tenter de procéder seul à des opérations comme l'installation ou le dé- placement de l'appareil. Le poids de cet appareil est d'environ 500 kg (1103 lb.);...
  • Page 16 Pour utiliser en toute sécurité Risque de décharge ou de choc électrique, d'électrocution ou d'incendie Cet appareil transmet une tension élevée. Cela peut créer des situations qui ne se produisent pas avec de l'équipement à basse tension. La prudence est de mise. ATTENTION Ne pas utiliser avec une source d'alimen- Ne jamais utiliser l'appareil si le câble d'ali-...
  • Page 17 Pour utiliser en toute sécurité L'encre, les liquides nettoyants et les liquides usés sont inflammables et toxiques ATTENTION PRUDENCE Ne jamais utiliser l'appareil près d'une S'assurer que le lieu de travail est bien flamme nue ou d'un appareil de chauffage aéré.
  • Page 18 Pour utiliser en toute sécurité Remarques importantes sur les opérateurs et le lieu de travail ATTENTION PRUDENCE Ne jamais faire fonctionner l'appareil en Ne jamais faire fonctionner l'appareil si on état de fatigue, ni après avoir consommé porte une cravate, un collier, des vête- de l'alcool ou des médicaments.
  • Page 19 Pour utiliser en toute sécurité Vignettes d'avertissement Des vignettes d'avertissement sont apposées pour qu'il soit facile de repérer les zones dangereuses. La signi- fication des vignettes est donnée ci-dessous. Respecter les avertissements. Ne jamais retirer les vignettes et ne pas les laisser s'encrasser. Inflammable L'encre et les liquides usés sont inflamma- bles.
  • Page 20 Pour utiliser en toute sécurité Attention : risque de pincement Mouvement lors de l'impression. Veiller à ne pas se coincer les doigts dans l'appareil. Attention : risque Attention : risque de pincement de pincement Mouvement lors de l'impression. Veiller Mouvement lors de à...

  • Page 21: Setup Guide

    Setup Guide...

  • Page 22: Installation

    1. Installation Emplacement and Installation Operations Emplacement and installation of the machine are to be carried out by a service technician. Do not emplace or move the machine yourself. WARNING The machine weighs approximately 500 kg (1103 lb.), and moving it requires special equip- ment and training.

  • Page 23: Deciding On An Installation Site

    1. Setup Guide Deciding On an Installation Site Install in a quiet, stable location offering good operating conditions. An unsuitable location can cause accident, fire, faulty operation, or breakdown. Install the machine in a location that is level, stable, and able to bear the weight of WARNING the machine.

  • Page 24: Temperature And Humidity

    1. Setup Guide Temperature and Humidity Maintain the specified temperature and humidity even when the machine is not in use. Temperatures that are too high may degrade the ink and cause malfunction. Temperatures that are too low may cause the ink to freeze and damage the heads.

  • Page 25: Included Items

    2. Included Items The following items are included with the machine. Make sure they are all present and accounted for. Power cord (*) Drain bottle SOL INK cleaning cartridges Pinch-roller pressure adjuster Ink-absorbing materials Cap-unit tool Hexagonal wrench Spanners Software RIP set CD-ROM User’s Manual Setup Guide (this document)

  • Page 26: Removing The Packing Materials 1

    3. Removing the Packing Materials 1 Removing Tape and Packing Materials from the Front Cover and Print Head Tape and packing materials are attached to the machine to protect it from vibration during transportation. When installation is complete, remove them. CAUTION Be sure to remove the packing materials according to the procedure.
  • Page 27 3. Removing the Packing Materials 1 Attach the cover on the right side of Screws the machine.

  • Page 28: Connecting Cables

    4. Connecting Cables Connecting the Power Cord WARNING Do not use with any electrical power supply that does not meet the ratings dis- played on the unit. Use with any other power supply may lead to fire or electrocution. Ground the unit with the ground wire. WARNING Failure to do so may result in risk of electrocution in the event of a mechanical problem.

  • Page 29: Connecting The Machine To A Computer

    4. Connecting Cables Connecting the Machine to a Computer Use a USB cable to make the connection to the computer. Be sure to make the connection between the machine and the computer during the course of installing the driver. USB cable Connecting the USB Cable Never attempt to connect a USB cable before starting installing the driver.

  • Page 30: Installing The Ink Cartridges

    5. Installing the Ink Cartridges Filling with Ink for the First Time Special procedures are required when installing ink cartridges for the first time. These are required only once, when installing ink cartridges for the first time after shipment from the factory. You first clean the print heads using cleaning fluid, then fill with the inks of the various colors.
  • Page 31 5. Installing the Ink Cartridges Switch on the power and make the initial settings. Close the front cover. Switch on the main power switch. Main power Press the F6 button. The display language toggles between English and Japa- nese each time you press the F6 button. Choose the language you wish to use.
  • Page 32 5. Installing the Ink Cartridges Clean the heads using the cleaning cartridges. Make sure the ink type matches the ink car- SELECT INK TYPE tridges. ECO-SOL 4 COLOR Press Make sure the drain bottle is installed. INSTALL DRAIN BOTTLE Press Insert cleaning cartridges into slots 1 and 2.
  • Page 33 5. Installing the Ink Cartridges Insert the ink cartridges for the respective colors. Before you insert the ink cartridge for each color, gently shake the cartridge. Insert the ink cartridge for each color. SET SOL CRT. 1 2 3 4 Flashing Match colors and insert FILLING INK...

  • Page 34: Removing The Packing Materials 2

    6. Removing the Packing Materials 2 Remove the Packing Materials From the Base Section Tape and packing materials are attached to the machine to protect it from vibration during transportation. When installation is complete, remove them. CAUTION Be sure to remove the tape and packing materials according to the procedure. Failure to follow the procedures may cause sudden operation or the like of the machine, which may result in unexpected injury.
  • Page 35 6. Removing the Packing Materials 2 Temporarily remove the drain bottle. Drain bottle Remove the packing materials. Packing material Packing material Attach the drain bottle again. Drain bottle...

  • Page 36: Matching The Machine To The Environment Where Installed

    7. Matching the Machine to the Environment Where Installed Adjust the machine to optimize its state to the environment where it is used. WARNING Do not touch the machine while it is in operation. If you do, your fingers or hand may get caught in the machine, which may lead to serious injury.
  • Page 37 7. Matching the Machine to the Environment Where Installed Press [LIFTER ORIGIN RESET]. Check that there is nothing on the table and press [NEXT]. Press the key to lower the lifter until the safety sensor detects the table. When the safety sensor detects the table, the [¤] mark changes to black.
  • Page 38 7. Matching the Machine to the Environment Where Installed Press [OK]. The origin detection operation starts. When this screen appears, the origin detection operation is complete. Press the [NEXT]. Press [RETURN] to return to the OPERATION screen.
  • Page 40 R3-041208...
