Instructions
4 Channel Upgrade Kit for
™
InvisiPac
For upgrading a 2 channel system to a 4 channel system. For professional use only.
Not approved for use in explosive atmospheres or hazardous locations.
Important Safety Instructions
Read all warnings and instructions in this manual and
in the InvisiPac Hot Melt Delivery System manual.
Save all instructions.
4 Channel Upgrade Kit 24V528
Hot Melt Delivery Systems
3A4404D
EN
