INSTALLATION AND OPERATION
Installation and Operation
Power
The LevelSCOUT comes with a 1/2 AA 3.6v lithium battery.
Connecting the LevelSCOUT to a Computer
In its cabled configuration, the sensor cable is terminated with a weather-resistant
connector. In its cableless configuration, the sensor is terminated with a weather-
resistant connector inside a screw-cap. Connect the weather-resistant connector to
your computer's USB port as shown below. (For alternate connection options, see
Appendix C.)
Screw-
cap
Sensor
Cableless
Configuration
Connect the sensor to your PC using INW's USB to RS485
adapter. (See Appendix C for alternate connections.)
Installing the Aqua4Plus Lite or Aqua4Plus Software
The LevelSCOUT comes with the Aqua4Plus Lite host software that is installed on your PC
or laptop. Use this software to program the datalogger, to retrieve data from the logger,
to view collected data, and to export data to external files for use with spreadsheets or
databases.
Refer to the Aqua4Plus Lite software manual for details on installing and using
Aqua4Plus Lite. LevelSCOUT can also be used with the full Aqua4Plus software.
Using the LevelSCOUT Without Aqua4Plus Lite or Aqua4Plus
Most users will use the LevelSCOUT with INW's Aqua4Plus Lite or Aqua4Plus software.
However, the LevelSCOUT is quite versatile, communicating via Modbus
you to use your own software or logging equipment. (See Appendix D for further
details.)
Seametrics • 253.872.0284
USB to RS485
Adapter
USB Port
Sensor
Page 6
INW LEVELSCOUT INSTRUCTIONS
PC or Laptop
Computer
RTU, allowing
®
inwusa.com
