Summary of Contents for Bartscher 110555
- Page 1 Instructions for Installation, Use and Maintenance 110555 110565 110585 110595 COD.: 3000ET APPLICARE ETICHETTA Ed. 03 - 04/2015 MATRICOLA...
- Page 2 Thank you for choosing our machine. The instructions for installation, maintenance and use found on the following pages have been prepared to ensure a long life and perfect operation of your unit. Please, do follow the instructions carefully. We have designed and built this machine using the latest innovative technologies. Now you shall take good care of it.
-
Page 3: Table Of Contents
TRANSLATION OF THE ORIGINAL INSTRUCTIONS CONTENTS Page WARNINGS INSTALLER SECTION 1. MACHINE INSTALLATION 1.1 Receiving the machine 1.2 Water connection 1.3 Electrical connection 1.4 Temperature adjustment 1.5 Rinse aid dispenser operation 1.6 Peristaltic rinse aid dispenser operation (optional) 1.7 Optional programmation 2. -
Page 4: Warnings
WARNINGS This instruction booklet must be kept with the machine for future con- sultation. If this machine is sold or transferred to other users, make sure the booklet always goes with the unit so that the new owner can have all the necessary information on operations and all relevant instructions. - Page 5 • Servicing of this machine must be performed by authorized personnel only. N.B.: Use genuine spare parts only. Non-genuine parts will void the warranty and the manufacturer will take no responsibility for any damage. • Do not use old water hoses, but new ones only. •...
- Page 6 page 24...
-
Page 7: Installer Section
INSTALLER SECTION ATTENTION: Once installation is complete, it is recommended to detach and preserve the installer’s guide section of this manual for future reference. 1. MACHINE INSTALLATION Receiving the machine After removing the packaging, make sure that the machine was not damaged during tran- sportation. -
Page 8: Temperature Adjustment
INSTALLER SECTION WARNING: check very carefully if the “ground connection” of the machine, is properly sized and fully effi cient, and that not too many units are connected on it. An undersized or poor “ground connection” might lead to corrosion and/or pitting effect on the stainless steel plates, even to perforation. -
Page 9: Optional Programmation
INSTALLER SECTION To adjust the capacity of the pump, use a screwdriver (see image 3). THE DISPENSERS ARE PRE-SET TO A 1,65 gr INTAKE OF PRODUCT FOLLOWING A TEST PHASE SYSTEM CHECK. THIS MEASUREMENT SHOULD BE ADJUSTED AC- CORDING TO THE TYPE OF RINSE AID USED AND WATER HARDNESS. Optional programmation 15186/T A) Dip switch... -
Page 10: Detergent Dispenser Installation
INSTALLER SECTION 2. DETERGENT DISPENSER RETROFIT Electrical connection Read the electric diagram, enclosed with the machine. ATTENTION: output arranged for electrical dispenser 230V max 2 Ampere. Pipe connection a) A Ø12mm hole must be made on the back wall of the appliance. On some models the Ø... -
Page 11: Pump Technical Data And Information
INSTALLER SECTION 3. TECHNICAL DATA AND USEFUL INFORMATION ON PUMPS Washing pump When the dishwasher has not been used for some time, check that the washing pump turns freely. To do this, operate using a screwdriver in the special slot on the ventilating side of the motor shaft. -
Page 12: Dataplate
INSTALLER SECTION Dataplate Code DWXXXX.YYYY CL/Part Model DESCRIPTION S/N DWXxxxxxxx Type ..400V 3N 50HZ ANNO PROD.: 2013 3500W 500W IPX3 Pressione Dinamica alimentazione idrica Pression dynamique arriveè d'eau 200-500 kPa Dynamic pressure water supply Dynamischer Druck asserreinlauf MADE IN ITALY Pressione dinamica vapore saturo Temperatura massima acqua in ingresso Pression dynamique vapeur satueèè... -
Page 13: User Section
USER SECTION 4. CONTROL PANEL AND RELATIVE SYMBOLS Cycle Light Indicator START push-button to start up cycle / select cycle ON / STAND BY indicator Salt shortage indicator Regeneration cycle indicator Supplementary cold rinse indicator Drain Pump indicator Drain Push-button (optional) Supplementary cold rinse push-button (optional) Regeneration push-button (optional) Switching –... -
Page 14: Cutlery And Crockery Loading
USER SECTION indicated by the lamp (see chap. 4). At the end of the washing cycle, a hot rinse cycle will take place. lamp (see chap. 4) will turn off when the cycle is fi nished. N.B.: At cycle-end, keeping the door closed, dishes will not dry. Take out the rack or keep the door open to allow the evaporation, helping the drying of the dishes. -
Page 15: Use Of Detergent
USER SECTION Detergent use The detergent shall be the NO FOAM type, suitable for industrial dishwashers. The use of good quality liquid detergents is recommended. The detergent shall be placed in the sump. Follow manufacturer recommendations for dosage. The machine can be ordered with an adjustable automatic detergent dispenser (always recommended). -
Page 16: Compliance With Hygiene Regulations And H.a.c.c
USER SECTION In the case of water hardness above 35°f it is advisable to install an exter- nal water softener. H.A.C.C.P. and hygiene regulations • The machines are equipped with a temperature indicator (led - chap. 4) which lights up when the boiler and the tub have reached the preset temperature (values set by the manufacturer). -
Page 17: Special Maintenance
USER SECTION Special Maintenance Once or twice a year have the machine inspected by a qualifi ed technician, in order to: 1 Clean the solenoid-valve(s) fi lters. 2 Remove scale from the heating elements. 3 Control the status of the seals. 4 Control for components integrity and/or consumption. -
Page 18: Ecological Features
USER SECTION 9. ECOLOGICAL ASPECTS Recommendations for optimal use of energy, water and additives Salt dosing A pre-set (by the manufacturer) quantity of salt is injected in the resins at each regeneration cycle. It is important to observe the number of regeneration cycles recommended in para- graph in order to avoid salt spills or lime deposits. - Page 19 USER SECTION Type of Problem Possible Causes Cure Glasses or dishes are not Not enough rinse aid. Increase dosage by turning the dispenser screw (see par. properly dried. Rinse aid dispenser). The rack is not suitable for the pots Use the suitable rack which gives the pots and tools an or the tools.
