LOGITECH RALLY AND RALLY PLUS IMPLEMENTATION GUIDE
e. SPEAKERS: The Rally speakers are ultra-low distortion designed specifically for speech
and enhanced echo canceling. When the system is uses in an application that enables
a microphone (such as video conferencing and recording applications) the speaker
output is binaural/double mono. When used in applications with no microphone input,
the speakers output stereo.
FEATURES
Connection
Volume
Sensitivity
Distortion
Speaker sampling rate
Features
f.

CABLES AND POWER SUPPLIES:

CABLE END 1
PTZ to TV hub USB C
Compute to Display or USB A
Table Hub
Display Hub to Table RJ45
Hub
Display Hub to Speaker Hard wired at Speak-
(x 2 in Rally Plus) er end
HDMI compute (x 2 in HDMI A
Rally Plus)
Mic Pod Hardwired at Mic Pod 12 pin
Mic Pod Hub Hardwired at Mic Pod
Hub
POWER SUPPLIES END 1
Table Hub C5
Display Hub C5
SPEAKER SPECS
Mini XLR cable connects to Rally Display Hub
for both signal and power
95dB SPL @ 1 W, 100dB SPL @ 7.5, both +/-2dB
at 1/2 meter
95+/-2dB SLP at 1/2 meter
200Hz-300Hz < 2.5%, 300Hz-10kHz < 1%@7.5W
48 kHz
• High-performance 3" (76 mm) driver with
rare-earth magnet
• Patent-pending suspension system elimi-
nates vibration-induced camera shake and
audio interference
END 2 LENGTH
USB C 2m
USB B 2m
RJ45 5m
Mini XLR 2.95 m
HDMI A 2 m
2.95 m
12 pin 2.95 m
END 2 LENGTH
DC jack plug (O.D = 3.5 m
5.5 mm, I.D = 2.1 mm,
L = 10.6 mm +/- 0.3)
DC jack plug (O.D = 2m
7.4 mm, I.D = 5.1 mm,
L = 11.7 mm +/- 0.3)
COMMENT
USB 3.1
USB 3.1
CAT6a
(max length = 50 m)
XLR (will also support
a user-supplied 3 m
extension cable)
HDMI 2.0
COMMENT
100-240V, 48V, 2A
100-240V, 19V, 4.74A
