LOGITECH RALLY AND RALLY PLUS IMPLEMENTATION GUIDE
h. OPTIONAL ELEMENTS:
i.
Additional Mic Pods: Rally supports up to seven (7) Mic Pods.
ii.
Mic Pod Hub: Used in microphone routing configurations where most of the cabling
is below the table. The Mic Pod Hub has three jacks that can be connected to a
combination of Mic Pods or other Mic Pod Hubs. Rally supports up to seven (7) Mic Pod
Hubs.
iii. Mounting Kit:
1.
Speaker wall mounts (x 2 for Rally Plus)
2. Camera wall mount
3. Display Hub mount
4. Table Hub mount
5. Cable clamps x 2
6. Screws and wall anchors
iv. Additional remote controls: Up to five (5) remote controls can be paired to Rally.
Having additional remote controls can be useful in larger rooms.
3. CONNECTING THE COMPONENTS
You have two options on where to place the computer running your meetings: the first (and
recommended method in most cases) is near the display and the second is at the table. If
you plan on the meeting computer at the display, please proceed to section 4. If you plan
on having the meeting computer at the table, please proceed to section 5.
a. NOTE ON COMPUTERS CONNECTED TO BOTH HUBS: Only one computer can have an
active connection to Rally.
i.
If Rally is powered on with computers connected to both the Table and Display Hubs,
the computer connected to the Table Hub will be the active computer.
ii.
If a second computer is connected while Rally is powered on, the first computer
connected remains the active computer.
p10
