DOREL ASIA
Model No:
BR1419B2WN (DARK WALNUT)
PEMBROOKE 2 IN 1
UPHOLSTERED CRIB
UPC CODE:
0-65857-16872-3
NOTE:
THIS INSTRUCTION BOOKLET
IMPORTANT
CONTAINS
SAFETY
INFORMATION. PLEASE READ AND
KEEP FOR FUTURE REFERENCE.
Lot number:
(TAKEN FROM CARTON)
_____________________________________
Date of purchase:
_______ / _______ / _______
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer service
department. We will replace the part FREE of charge.
Tel #: 1-800-295-1980
NEED HELP!
CALL US FOR ASSISTANC
E-Mail: das@dorel.com
1-800-295-1980
Fax #: 514-353-7819
DO NOT RETURN PRODU
E-MAIL:DAS@DOREL.CO

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Bertini Pembrooke Upholstered Crib BR1419B2WN and is the answer not in the manual?

Questions and answers

Related Manuals for Dorel Asia Bertini Pembrooke Upholstered Crib BR1419B2WN

Summary of Contents for Dorel Asia Bertini Pembrooke Upholstered Crib BR1419B2WN

  • Page 1 DOREL ASIA Model No: BR1419B2WN (DARK WALNUT) PEMBROOKE 2 IN 1 UPHOLSTERED CRIB UPC CODE: 0-65857-16872-3 NOTE: THIS INSTRUCTION BOOKLET IMPORTANT CONTAINS SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Lot number: (TAKEN FROM CARTON) _____________________________________ Date of purchase: _______ / _______ / _______ DO NOT RETURN PRODUCT TO THE STORE.
  • Page 2 CUSTOMER SERVICE If you are missing parts or have any questions about this product, contact our customer service representative first! CALL 1-800-295-1980 You can also order parts by writing to the address listed below. Please include the product model number, color and a detailed description of the part.

  • Page 3: Care And Cleaning

    Check bolts/screws periodically and tighten them if necessary. LIMITED WARRANTY Dorel Asia warrants its product to be free from defects in material and workmanship and agrees to remedy any such defect. This warranty covers 1 year from the date of original purchase. This warranty is valid only upon presentation of proof of purchase.

  • Page 4: Hardware List

    PEMBROOKE 2 IN 1 UPHOLSTERED CRIB BR1419B2WN HARDWARE LIST Ø10 X 32mm WOOD DOWEL ALLEN KEY 10 PCS 1 PC Ø1/4" X 15mm X 54mm Ø5/16" X 13 X 1.5mmT BOLT SPRING WASHER 20 PCS 20 PCS 30 X 15mm X 7.5mm Ø1/4"...

  • Page 5: Parts List

    PEMBROOKE 2 IN 1 UPHOLSTERED CRIB BR1419B2WN PARTS LIST SIDE PANEL FRONT/BACK PANEL BOTTOM RAIL 2 PCS 2 PCS 2 PCS GUARD RAIL MATTRESS SUPPORT 1 PC 1 PC...
  • Page 6 PEMBROOKE 2 IN 1 UPHOLSTERED CRIB BR1419B2WN CRIB ASSEMBLY INSTRUCTION NOTE: When inserting bolts, turn clockwise until tighten. Then loosen 1/2 - 3/4 of a turn. After crib is completely assembled, return to each bolt and tighten. Use wax or soap on all bolts to facilitate assembly.
  • Page 7 PEMBROOKE 2 IN 1 UPHOLSTERED CRIB BR1419B2WN STEP 1 Insert wood dowels (1) into side panels (A). Attach bottom rails (C) to side panels (A) with bolts (3), spring washers (4) and curved nuts (5) as shown. Use Allen Key (2) to tighten all bolts (3).
  • Page 8 PEMBROOKE 2 IN 1 UPHOLSTERED CRIB BR1419B2WN STEP 2 Attach mattress support (E) to side panels (A) with mattress support bolts (6) and spring washers (7). Use Allen Key (2) to tighten the bolts (6). INCORRECT- Raised edge should face down -this photo shows mattress support is upside down.
  • Page 9 PEMBROOKE 2 IN 1 UPHOLSTERED CRIB BR1419B2WN STEP 3 Insert wood dowels (1) into bottom rails (C). Slide the front/back panels (B) down side panels (A) to attach them to bottom rails (C).
  • Page 10 PEMBROOKE 2 IN 1 UPHOLSTERED CRIB BR1419B2WN STEP 4 Secure front/back panels (B) to side panels (A) with bolts (3) and spring washers (4) as shown. Use Allen Key (2) to tighten all bolts (3).
  • Page 11 PEMBROOKE 2 IN 1 UPHOLSTERED CRIB BR1419B2WN TODDLER BED & DAY BED ASSEMBLY: STARTING FROM CRIB WARNINGS: * ANY MATTRESS USED IN THIS CRIB MUST BE AT LEAST 27-1/4 INCHES BY 51-5/8 INCHES (69CM BY 131CM) WITH A THICKNESS NOT EXCEEDING 6 INCHES (15CM). * The toddler bed or day bed is not intended for children under 15 months of age or over 50 lbs (22.7 kgs).
  • Page 12 PEMBROOKE 2 IN 1 UPHOLSTERED CRIB BR1419B2WN STEP 5 Attach guard rail (D) to bottom rail (C) with bolts (6), wood dowels (1),and spring washers (7) as shown. Use Allen key (2) to tighten all bolts (6).
  • Page 13 PEMBROOKE 2 IN 1 UPHOLSTERED CRIB BR1419B2WN CAUTION: This unit is intended for use only with the products and/or maximum weights indicated. Use with other products and/or products heavier than the maximum weights indicated may result in instability or cause possible injury. ANY MATTRESS USED IN THIS CRIB MUST BE AT LEAST 27-1/4 INCHES BY 51-5/8 INCHES (69CM BY 131CM) WITH...
  • Page 14 MODEL #: BR1419B2WN Customer Service PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S). Customer Service Phone Number 1-800-295-1980 Email: das@dorel.com Customer Service Fax Number 514-353-7819 Request Date: Name: Shipping Address:...
