DOREL ASIA
Model No:
DA6504B4 (Walnut)
Crib
UPC CODE:
0-65857-16508-1
Lot number:
(TAKEN FROM CARTON)
_____________________________________
Date of purchase:
_______ / _______ / _______
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer service
department. We will replace the part FREE of charge.
Tel #: 1-800-295-1980
NEED HELP!
CALL US FOR ASSISTAN
E-Mail: das@dorel.com
1-800-295-1980
DO NOT RETURN PRODU
E-MAIL:DAS@DOREL.CO

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DA6504B4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Dorel Asia DA6504B4

  • Page 1 DOREL ASIA Model No: DA6504B4 (Walnut) Crib UPC CODE: 0-65857-16508-1 Lot number: (TAKEN FROM CARTON) _____________________________________ Date of purchase: _______ / _______ / _______ DO NOT RETURN PRODUCT TO THE STORE. If a part is missing or damaged, contact our customer service department.
  • Page 2 CUSTOMER SERVICE If you are missing parts or have any questions about this product, contact our customer service representative first! CALL 1-800-295-1980 You can also order parts by writing to the address listed below. Please include the product model number, color and a detailed description of the part. Customer Service Department No.
  • Page 3: Care And Cleaning

    Check bolts/screws periodically and tighten them if necessary. LIMITED WARRANTY DOREL ASIA warrants its product to be free from defects in material and workmanship and agrees to remedy any such defect. This warranty covers 1 year from the date of original purchase.
  • Page 4: Hardware List

    CRIB DA6504B4 HARDWARE LIST Ø10mm x 50mm Ø1/4" x 3-1/8" WOOD DOWEL LONG HEX SOCKET HEAD BOLT 12 PCS 6 PCS Ø1/4" x 2-1/2" Ø1/4" x 5/8" SHORT HEX SOCKET HEAD BOLT MATTRESS SUPPORT BOLT 14 PCS 16 PCS Ø6mm x 10mm x 1.2mm...
  • Page 5: Parts List

    CRIB DA6504B4 PARTS LIST LEFT POST RIGHT POST LEFT SIDE PANEL 1 PC 1 PC 1 PC RIGHT SIDE PANEL BACK PANEL FRONT PANEL 1 PC 1 PC 1 PC GUARDRAIL MATTRESS SUPPORT 1 PC 1 PC...
  • Page 6 CRIB DA6504B4 STEP 1: Insert the wood dowels (1) into the left and right side panels (C & D). Attach the left and right posts (A & B) to the side panels (C & D) with short hex socket head bolts (3) as shown.
  • Page 7 CRIB DA6504B4 STEP 2: Insert wood dowels (1) into the left side panel (C). Attach the left side panel (C) to the back panel (E) with long hex socket head bolts (2) as shown. Use Allen key (6) to tighten the bolts.
  • Page 8 CRIB DA6504B4 STEP 3: Attach the mattress support (H) to the left and right side panels (C & D) with mattress support bolts (4) and spring washers (5). Use Allen key (6) to tighten the bolts. NOTE: Do not fully tighten bolts. This will facilitate assembly in next step.
  • Page 9 CRIB DA6504B4 STEP 4: Attach the front panel (F) to left and right posts (A & B) with wood dowels (1) and short hex socket head bolts (3) as shown. Use Allen key (6) to tighten the bolts. NOTE: Fully tighten all bolts installed in previous step.
  • Page 10 CRIB DA6504B4 WARNINGS: * Any mattress used in this crib must be at least 27-1/4 inches by 51-5/8 inches (69cm by 131cm) with a minimum thickness of 4 inches (10cm) but not exceeding 6 inches (15cm). * The day bed is not intended for children under 15 months of age or over 50 pounds (22.7 kgs).
  • Page 11 CRIB DA6504B4 FULL SIZE BED ASSEMBLY INSTRUCTION (HEADBOARD AND FOOTBOARD ONLY) FULL SIZE CONVERSION RAILS AND LEGS ARE NOT INCLUDED. DIAGRAMS ARE FOR REFERENCE ONLY. BED RAILS MAY DIFFER FROM ILLUSTRATION. BACK PANEL (E) STEP 1: Attach the full size conversion rails (not included) to the back panel (E) and posts (A &...
  • Page 12 CRIB DA6504B4 CAUTION: This unit is intended for use only with the products and/or maximum weights indicated. Use with other products and/or products heavier than the maximum weights indicated may result in instability or cause possible injury. ANY MATTRESS USED IN THIS CRIB...
  • Page 13 MODEL #: DA6504B4 Customer Service PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S). Customer Service Phone Number 1-800-295-1980 Email: das@dorel.com Customer Service Fax Number 514-353-7819...
