DOREL ASIA

Model No:

DA6792 (ESPRESSO)

NURSERY IN A BOX

UPC CODE:

2 IN 1 CRIB

0-65857-16661-3

NOTE:

THIS INSTRUCTION BOOKLET

CONTAINS IMPORTANT SAFETY

INFORMATION. PLEASE READ AND

KEEP FOR FUTURE REFERENCE.

Lot number:

(TAKEN FROM CARTON)

_____________________________________

Date of purchase:

_______ / _______ / _______

DO NOT RETURN PRODUCT TO THE STORE.

If a part is missing or damaged, contact our customer service

department. We will replace the part FREE of charge.

Tel #: 1-800-295-1980

NEED HELP!

E-Mail: das@dorel.com

CALL US FOR ASSISTANC

Fax #: 514-353-7819

1-800-295-1980

DO NOT RETURN PRODU

Need help?

Do you have a question about the baby Relax DA6792 and is the answer not in the manual?

Questions and answers

Summary of Contents for Dorel Asia baby Relax DA6792

Page 1 DOREL ASIA Model No: DA6792 (ESPRESSO) NURSERY IN A BOX UPC CODE: 2 IN 1 CRIB 0-65857-16661-3 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Lot number: (TAKEN FROM CARTON) _____________________________________ Date of purchase: _______ / _______ / _______ DO NOT RETURN PRODUCT TO THE STORE.
Page 2 CUSTOMER SERVICE If you are missing parts or have any questions about this product, contact our customer service representative first! CALL 1-800-295-1980 You can also order parts by writing to the address listed below. Please include the product model number, color and a detailed description of the part.
Page 3 Check bolts/screws periodically and tighten them if necessary. LIMITED WARRANTY Dorel Asia warrants its product to be free from defects in material and workmanship and agrees to remedy any such defect. This warranty covers 1 year from the date of original purchase. This warranty is valid only upon presentation of proof of purchase.
Page 4 NURSERY IN A BOX 2 IN 1 CRIB DA6792 HARDWARE LIST Ø1/4" X 13mm X 38mm Ø1/4" X 13mm X 70mm BOLT BOLT 18 PCS 8 PCS Ø1/4" X 13mm X 15mm Ø1/4" X 13mm X 60mm MATTRESS SUPPORT BOLT BOLT 16 PCS 10 PCS...
Page 5 NURSERY IN A BOX 2 IN 1 CRIB DA6792 PARTS LIST FRONT POST BACK POST BACK PANEL LEFT SIDE PANEL 2 PCS 2 PCS 1 PC 1 PC RIGHT SIDE PANEL FRONT PANEL CRIB FRONT RAIL MATTRESS SUPPORT 1 PC 1 PC 1 PC 1 PC...
Page 6 NURSERY IN A BOX 2 IN 1 CRIB DA6792 CRIB ASSEMBLY INSTRUCTION NOTE: When inserting bolts, turn clockwise until tight. Then loosen 1/2 - 3/4 of a turn. After crib is completely assembled, return to each bolt and tighten. Use wax or soap on all bolts to facilitate assembly.
Page 7 NURSERY IN A BOX 2 IN 1 CRIB DA6792 STEP 1 Insert wood dowels (6) and barrel nuts (7) into left side panel (D) as shown. Attach left front post (A1) & left back post (B1) to left side panel (D) with bolts (2). Use Allen Key (5) to tighten the bolts.
Page 8 NURSERY IN A BOX 2 IN 1 CRIB DA6792 STEP 2 Attach the back panel (C) to left back post (B1) o with bolts (4) and barrel nuts (7) as shown. Use Allen Key (5) to tighten all bolts (4). Repeat this step to attach back panel (C) to right back post (B2).
Page 9 NURSERY IN A BOX 2 IN 1 CRIB DA6792 STEP 3 Attach mattress support (H) to the posts with mattress support bolts (3). Use Allen key (5) to tighten the mattress support bolts (3). ③ INCORRECT- Raised edge should face down -this photo shows mattress support is...
Page 10 NURSERY IN A BOX 2 IN 1 CRIB DA6792 STEP 4 Insert barrel nuts (7) into both ends of crib front rail (G). Attach crib front rail (G) to left front post (A1) with bolt (4). Use Allen key (5) to tighten the bolt. Repeat this step to attach crib front rail (G) to right front post (A2).
Page 11 NURSERY IN A BOX 2 IN 1 CRIB DA6792 STEP 5 Insert barrel nuts (7) into front panel (F) as shown. Attach front panel (F) to left front post (A1) with bolts (1 & 4). Use Allen key (5) to tighten the bolts (1 & 4). Repeat this step to attach front panel (F) to right front post (A2).
Page 12 NURSERY IN A BOX 2 IN 1 CRIB DA6792 STEP 6 Fasten the front panel (F) and crib front rail (G) with bolts (4). Use Allen key (5) to tighten the bolts (4). NOTE: DO NOT throw away this instruction manual. Use the crib pouch attached to the mattress support to store this manual for future use.
Page 13 NURSERY IN A BOX 2 IN 1 CRIB DA6792 WARNINGS: * ANY MATTRESS USED IN THIS CRIB MUST BE AT LEAST 27-1/4 INCHES BY 51-5/8 INCHES (69CM BY 131CM) WITH A MINIMUM THICKNESS OF 4 INCHES (10CM) BUT NOT EXCEEDING 6 INCHES (15CM). * The day bed is not intended for children under 15 months of age or over 50 lbs (22.7 kgs).
Page 14 NURSERY IN A BOX 2 IN 1 CRIB DA6792 CHANGING TABLE ASSEMBLY INSTRUCTION...
Page 15 NURSERY IN A BOX 2 IN 1 CRIB DA6792 STEP 1 Insert wood dowels (6) into upper rail (K). Attach upper rail (K), top panel rail (L), and middle rails (M) to left side frame (I) with bolts (1). Use Allen key (5) to tighten the bolts (1).
Page 16 NURSERY IN A BOX 2 IN 1 CRIB DA6792 STEP 2 Slide top panel (N) and shelf panels (O) into the grooves of rails (L & M). Make sure they rest inside the grooves of left side frame (I).
Page 17 NURSERY IN A BOX 2 IN 1 CRIB DA6792 STEP 3 Insert wood dowels (6) into upper rail (K). Attach upper rail (K), top panel rail (L), and middle rail (M) to left side frame (I) with bolts (1). Use Allen key (5) to tighten the bolts (1).
Page 18 NURSERY IN A BOX 2 IN 1 CRIB DA6792 STEP 4 Insert wood dowels (6) into upper rails (K) on both side. Attach right side frame (J) to the assembled unit with bolts (1). Use Allen key (5) to tighten the bolts.
Page 19 NURSERY IN A BOX 2 IN 1 CRIB DA6792 CAUTION: This unit is intended for use only with the products and/or maximum weights indicated. Use with other products and/or products heavier than the maximum weights indicated may result in instability or cause possible injury. Maximum weight not to exceed 50 pounds when The maximum...
Page 20 MODEL #: DA6792 Customer Service PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S). Customer Service Phone Number 1-800-295-1980 Email: das@dorel.com Customer Service Fax Number 514-353-7819 Request Date: Name: Shipping Address:...
