DOREL ASIA
TODDLER BED
WM1646RWN
WM1646RC
WM1646RN
WM1646RW
WM1646E
0-65857-14157-3
0-65857-14156-6
0-65857-14155-9
0-65857-14160-3
0-65857-16242-4
THIS INSTRUCTION BOOKLET
CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE
READ AND KEEP FOR
FUTURE REFERENCE.
DATE OF PURCHASE:
______ / ______ / ______
NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, Contact our
customer service department. We will
replace the part FREE of charge.
MODEL NO:
WALNUT
CHERRY
NATURAL
WHITE
ESPRESSO
UPC CODE:
WALNUT
CHERRY
NATURAL
WHITE
ESPRESSO
NOTE:
LOT NUMBER:
(TAKEN FROM CARTON)
Tel # : 1-800-295-1980
E-Mail: das@dorel.com
Fax #: 514-353-7819

Advertisement

loading
Need help?

Need help?

Do you have a question about the WM1646 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dorel Asia WM1646 Series

Summary of Contents for Dorel Asia WM1646 Series

  • Page 1 DOREL ASIA MODEL NO: WM1646RWN WALNUT WM1646RC CHERRY TODDLER BED WM1646RN NATURAL WM1646RW WHITE WM1646E ESPRESSO UPC CODE: 0-65857-14157-3 WALNUT 0-65857-14156-6 CHERRY 0-65857-14155-9 NATURAL 0-65857-14160-3 WHITE 0-65857-16242-4 ESPRESSO NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
  • Page 2 CUSTOMER SERVICE If you are missing parts or have any questions about this product, contact our customer service representative first! CALL 1-800-295-1980 You can also order parts by writing to the address listed below. Please include the product model number, color and a detailed description of the part.

  • Page 3: Limited Warranty

    Check bolts periodically and tighten if necessary. LIMITED WARRANTY Dorel Asia warrants its product to be free from defects in material and workmanship and agrees to remedy any such defect. This warranty covers 1 year from the date of original purchase. This warranty is valid only upon presentation of proof of purchase.

  • Page 4: Hardware List

    TODDLER BED WM1646RWN / WM1646RC / WM1646RN / WM1646RW / WM1646E HARDWARE LIST Φ 1/4" x 1-3/4" Φ 1/4" x 2-1/2" HEX SOCKET HEAD BOLT HEX SOCKET HEAD BOLT 18 PCS 10 PCS Φ 1/4" x 1/2" BARREL NUT ALLEN KEY 10 PCS 1 PC Φ...

  • Page 5: Parts List

    TODDLER BED WM1646RWN / WM1646RC / WM1646RN / WM1646RW / WM1646E PARTS LIST LEFT HEADBOARD POST RIGHT HEADBOARD POST LEFT FOOTBOARD POST 1 PC 1 PC 1 PC RIGHT FOOTBOARD POST CYLINDER TOP & BOTTOM CROSS 1 PC 2 PCS 4 PCS WIDE HEADBOARD SLAT NARROW HEADBOARD SLAT...
  • Page 6 TODDLER BED WM1646RWN / WM1646RC / WM1646RN / WM1646RW / WM1646E STEP 1 One of the top & bottom cross (F) has a warning label on it, Do not use it in this step. Insert wood dowels (5) into ends of top & bottom cross (F). Attach right headboard post (B) to the top cross (F) using hex socket head bolt (1) as shown.
  • Page 7 TODDLER BED WM1646RWN / WM1646RC / WM1646RN / WM1646RW / WM1646E STEP 2 Insert wide headboard slat (G) and narrow headboard slats (H) into the holes of the top cross (F). Push the headboard slats to secure them in place.
  • Page 8 TODDLER BED WM1646RWN / WM1646RC / WM1646RN / WM1646RW / WM1646E STEP 3 Use the top & bottom cross (F) with a warning label in this step. Insert wood dowels (5) into ends of the bottom cross (F). Insert stoppers (8) into the holes of the bottom cross (F). Insert bottom cross (F) to the right headboard post (B).
  • Page 9 TODDLER BED WM1646RWN / WM1646RC / WM1646RN / WM1646RW / WM1646E STEP 4 Insert metal dowels (7) into ends of cylinder (E). Attach cylinder (E) to the right headboard post (B) using hex socket head bolt (1) as shown. Use Allen Key (4) to tighten the bolt.
  • Page 10 TODDLER BED WM1646RWN / WM1646RC / WM1646RN / WM1646RW / WM1646E STEP 5 Attach the left headboard post (A) to the top & bottom cross (F) and cylinder (E) using hex socket head bolt (1) as shown. Use Allen Key (4) to tighten the bolts. NOTE: Do not fully tighten bolts.
  • Page 11 TODDLER BED WM1646RWN / WM1646RC / WM1646RN / WM1646RW / WM1646E STEP 6 Insert wood dowels (5) into ends of top cross (F). Attach the left footboard post (C) to the top cross (F) using hex socket head bolt (1) as shown. Use Allen Key (4) to tighten the bolt.
  • Page 12 TODDLER BED WM1646RWN / WM1646RC / WM1646RN / WM1646RW / WM1646E STEP 7 Insert wide footboard slat (I) and narrow footboard slats (J) into the holes of the top cross (F). Push the footboard slats up and to secure them in place.
  • Page 13 TODDLER BED WM1646RWN / WM1646RC / WM1646RN / WM1646RW / WM1646E Insert wood Insert wood dowels (5) into ends of the bottom cross (F). Insert stoppers (8) into the holes of the bottom cross (F). Insert the bottom cross (F) to the left footboard post (C). Insert the wide footboard slat (I) and narrow footboard slats (J) into the holes of the bottom cross (F).
  • Page 14 TODDLER BED WM1646RWN / WM1646RC / WM1646RN / WM1646RW / WM1646E STEP 9 Insert metal dowels (7) into ends of cylinder (E). Attach cylinder (E) to the left footboard post (C) using hex socket head bolt (1) as shown. Use Allen Key (4) to tighten the bolt. NOTE: Do not fully tighten bolt.
  • Page 15 TODDLER BED WM1646RWN / WM1646RC / WM1646RN / WM1646RW / WM1646E STEP 10 Attach the right footboard post (D) to the top & bottom cross (F) and cylinder (E) using hex socket head bolt (1) as shown. Use Allen Key (4) to tighten the bolts. NOTE: Do not fully tighten bolts.
  • Page 16 TODDLER BED WM1646RWN / WM1646RC / WM1646RN / WM1646RW / WM1646E PRE DRILLED HOLE FACING UP STEP 11 Insert wood dowels (6) into ends of the wide support slats (O) and narrow support slats (P) as shown. Insert barrel nut (3) into the hole on the wide surface of center support slat (N). Ensure the barrel nut (3) is flush with center support slat (N).
  • Page 17 TODDLER BED WM1646RWN / WM1646RC / WM1646RN / WM1646RW / WM1646E PRE DRILLED HOLE FACING UP STEP 12 Insert barrel nut (3) into the hole on the wide surface of center support slat (N). Ensure the barrel nut(3) is flush with center support slat (N). Attach the left side rail (K) to the wide support slat (O) and narrow support slat (P).
  • Page 18 TODDLER BED WM1646RWN / WM1646RC / WM1646RN / WM1646RW / WM1646E STEP 13 Insert barrel nuts (3) into both ends of the left and right side rail (K & L). Attach the headboard and footboard to the left and right side rail (K & L) by threading hex socket head bolts (2) through the headboard post (A &...
  • Page 19 DIAGRAM 2 Headboar TODDLER BED WM1646RWN / WM1646RC / WM1646RN / WM1646RW / WM1646E STEP 14 Attach the guardrails (M) to the headboard post (A & B) with hex socket head bolts (1). Attach the guardrails (M) to the left and right side rails (K & L) with hex socket head bolts (1) as shown.
  • Page 20 MODEL #: WM1646RWN / WM1646RC / WM1646RN / WM1646RW / WM1646E Customer Service PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S). Customer Service Phone Number 1-800-295-1980 Email: das@dorel.com Customer Service Fax Number 514-353-7819 Request Date:...
