Dorel Asia CRIB DA5674 Instruction Booklet
  1. Manuals
  2. Brands
  3. Dorel Asia Manuals
  4. Baby & Toddler Furniture
  5. CRIB DA5674
  6. Instruction booklet

Dorel Asia CRIB DA5674 Instruction Booklet

4 in 1 convertible
Hide thumbs

Advertisement

Quick Links

Download this manual
DOREL ASIA
Model No:
4 IN 1 CONVERTIBLE CRIB
DA5674
UPC CODE:
0-65857-16011-6
NOTE:
THIS INSTRUCTION BOOKLET
CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND
KEEP FOR FUTURE REFERENCE.
Lot number:
(TAKEN FROM CARTON)
_____________________________________
Date of purchase:
_______ / _______ / _______
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer service
department. We will replace the part FREE of charge.
NEED HELP!
Tel #: 1-800-295-1980
CALL US FOR A
E-Mail: das@dorel.com
1-800-295-1980
Fax #: 514-353-7819
DO NOT RETUR
