Dorel Asia baby relax DA6785 Assembly Instructions Manual

Dorel Asia baby relax DA6785 Assembly Instructions Manual

4 in 1 crib
Hide thumbs

Advertisement

Quick Links

Download this manual
DOREL ASIA
4 IN 1 CRIB
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer service
department. We will replace the part FREE of charge.
DA6785 (ESPRESSO & WALNUT)
THIS INSTRUCTION BOOKLET
CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND
KEEP FOR FUTURE REFERENCE.
_____________________________________
_______ / _______ / _______
NEED HELP!
CALL US FOR ASSISTAN
1-800-295-1980
DO NOT RETURN PROD
E-MAIL:DAS@DOREL.C
Model No:
UPC CODE:
0-65857-16657-6
NOTE:
Lot number:
(TAKEN FROM CARTON)
Date of purchase:
Tel #: 1-800-295-1980
E-Mail: das@dorel.com
Fax #: 514-353-7819

Advertisement

loading
Need help?

Need help?

Do you have a question about the baby relax DA6785 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dorel Asia baby relax DA6785

Summary of Contents for Dorel Asia baby relax DA6785

  • Page 1 DOREL ASIA Model No: DA6785 (ESPRESSO & WALNUT) UPC CODE: 0-65857-16657-6 4 IN 1 CRIB NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Lot number: (TAKEN FROM CARTON) _____________________________________ Date of purchase: _______ / _______ / _______ DO NOT RETURN PRODUCT TO THE STORE.
  • Page 2 CUSTOMER SERVICE If you are missing parts or have any questions about this product, contact our customer service representative first! CALL 1-800-295-1980 You can also order parts by writing to the address listed below. Please include the product model number, color and a detailed description of the part.

  • Page 3: Care And Cleaning

    Check bolts/screws periodically and tighten them if necessary. LIMITED WARRANTY DOREL ASIA warrants its product to be free from defects in material and workmanship and agrees to remedy any such defect. This warranty covers 1 year from the date of original purchase. This warranty is valid only upon presentation of proof of purchase.

  • Page 4: Hardware List

    4 IN 1 CRIB DA6785 HARDWARE LIST Ø1/4" X 13mm X 100mm Ø1/4" X 13mm X 85mm BOLT BOLT 10 PCS 2 PCS Ø1/4" X 13mm X 75mm Ø1/4" X 13mm X 50mm BOLT BOLT 8 PCS 8 PCS Ø1/4" X 13mm X 38mm Ø1/4"...

  • Page 5: Parts List

    4 IN 1 CRIB DA6785 PARTS LIST FRONT POST BACK POST BACK PANEL 2 PCS 2 PCS 1 PC LEFT SIDE PANEL RIGHT SIDE PANEL FRONT PANEL 1 PC 1 PC 1 PC SIDE PANEL TOP RAIL FRONT PANEL TOP RAIL FRONT PANEL BOTTOM 2 PCS 1 PC...
  • Page 6 4 IN 1 CRIB DA6785 CRIB ASSEMBLY INSTRUCTION NOTE: When inserting bolts, turn clockwise until tight. Then loosen 1/2 - 3/4 of a turn. After crib is completely assembled, return to each bolt and tighten. Use wax or soap on all bolts to facilitate assembly.
  • Page 7 4 IN 1 CRIB DA6785 STEP 1 Insert wood dowels (9) into side panel top rail (G). Attach side panel top rail (G) to left side panel (D) with bolts (3). Use Allen Key (8) to tighten all bolts (3). Repeat this step to attach side panel top rail (G) onto right side panel (E).
  • Page 8 4 IN 1 CRIB DA6785 STEP 2 Attach left side panel (D) to left back post (B1) with bolts (4). Use Allen Key (8) to tighten all bolts (4). Repeat this step to attach right side panel (E) to right back post (B2). ④...
  • Page 9 4 IN 1 CRIB DA6785 STEP 3 Insert wood dowels (9) into front panel top rail (H). Attach front panel top rail (H) to front panel (F) with bolts (3). Use Allen Key (8) to tighten all bolts (3). ③ ⑨...
  • Page 10 4 IN 1 CRIB DA6785 STEP 4 Attach front panel bottom rail (I) to front panel (F) with bolts (2). Use Allen Key (8) to tighten the bolts (2). ②...
  • Page 11 4 IN 1 CRIB DA6785 STEP 5 Insert wood dowels (9) and barrel nut (7) into front panel (F) and front panel bottom rail (I) as shown. Attach front posts (A1 & A2) to front panel (F) and front panel bottom rail (I) using bolts (1). Use Allen Key (8) to tighten the bolts (1).
  • Page 12 4 IN 1 CRIB DA6785 STEP 6 Attach left side panel (D) and right side panel (E) to the assembled front panel (F) using bolts (4). Use Allen Key (8) to tighten the bolts (4). INSIDE NOTE: The lower rails of side panels (D & E) are labeled "INSIDE."...
  • Page 13 4 IN 1 CRIB DA6785 STEP 7 Attach mattress support (K) to the posts with mattress support bolts (6). Use Allen Key (8) to tighten the bolts (6). ⑥ INCORRECT- Raised edge should face down -this photo shows mattress support is ...
  • Page 14 4 IN 1 CRIB DA6785 STEP 8 Insert wood dowel (9) into back posts (B1 & B2). Insert barrel nuts (7) into back panel ( C) as shown. Attach back panel (C) to back posts (B1 & B2) with bolts (1). Use Allen Key (8) to tighten the bolts (1).
  • Page 15 4 IN 1 CRIB DA6785 NOTE: DO NOT throw away this instruction manual. Use the crib pouch attached to the mattress support to store this manual for future use. WARNINGS: * ANY MATTRESS USED IN THIS CRIB MUST BE AT LEAST 27-1/4 INCHES BY 51-5/8 INCHES (69CM BY 131CM) WITH A MINIMUM THICKNESS OF 4 INCHES (10CM) BUT NOT EXCEEDING 6 INCHES (15CM).
  • Page 16 4 IN 1 CRIB DA6785 DAY BED ASSEMBLY: STARTING FROM CRIB STEP 1: Unscrew bolts (4) from front posts (A1 & A2) with Allen Key (8) as shown below. STEP 2: Unscrew bolts (2) underneath the front panel bottom rail (I) with Allen Key (8) to detach the front panel from the crib.
  • Page 17 4 IN 1 CRIB DA6785 DAY BED ASSEMBLY: STARTING FROM CRIB STEP 3: Unscrew bolts (1) on post (A1 & A2) with Allen Key (8). STEP 4: Detach front panel (F) from front posts (A1 & A2) and front panel bottom rail (I).
  • Page 18 4 IN 1 CRIB DA6785 DAY BED ASSEMBLY: STARTING FROM CRIB STEP 5 : Attach front posts (A1 & A2) to front panel bottom rail (I) using bolts (1) and wood dowels (9) as shown.
  • Page 19 4 IN 1 CRIB DA6785 DAY BED ASSEMBLY: STARTING FROM CRIB STEP 6: Attach the assembled front posts (A1 & A2) to the crib frame using bolts (4) as shown below.
  • Page 20 4 IN 1 CRIB DA6785 DAY BED ASSEMBLY: STARTING FROM CRIB STEP 7: Attach caps (J) to front posts (A1 & A2) using wood dowels (10 ) and bolts (5) as shown. NOTE: If mattress support (K) is not in the lowest position, unscrew bolts (6) from left & right posts (A1, A2, B1 &...
  • Page 21 4 IN 1 CRIB DA6785 FULL SIZE BED ASSEMBLY INSTRUCTION (HEADBOARD ONLY) NOTE: FULL SIZE CONVERSION RAILS ARE NOT INCLUDED. DIAGRAMS ARE FOR REFERENCE ONLY. BED RAILS MAY DIFFER FROM ILLUSTRATION. STEP 1 Attach the full size conversion rails (not included) to the assembled headboard (C, B1 and B2) .
  • Page 22 4 IN 1 CRIB DA6785 FULL SIZE BED ASSEMBLY INSTRUCTION (HEADBOARD AND FOOTBOARD) NOTE: FULL SIZE CONVERSION RAILS ARE NOT INCLUDED. DIAGRAMS ARE FOR REFERENCE ONLY. BED RAILS MAY DIFFER FROM ILLUSTRATION. STEP 1 Attach the full size conversion rails (not included) to assembled headboard (C) and footboard (B1, B2, F, H, I).
  • Page 23 4 IN 1 CRIB DA6785 CAUTION: This unit is intended for use only with the products and/or maximum weights indicated. Use with other products and/or products heavier than the maximum weights indicated may result in instability or cause possible injury. ANY MATTRESS USED IN THIS CRIB MUST BE AT LEAST 27-1/4 INCHES BY 51-5/8 INCHES (69CM...

  • Page 24: Customer Service

    MODEL #: DA6785 Customer Service PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S). Customer Service Phone Number 1-800-295-1980 Email: das@dorel.com Customer Service Fax Number 514-353-7819 Request Date: Name: Shipping Address:...
