DOREL ASIA
Model No:
BR1330B4 (MIST)
HEIDI KLUM
UPC CODE:
4 IN 1 CRIB
0-65857-16638-5
NOTE:
THIS INSTRUCTION BOOKLET
CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND
KEEP FOR FUTURE REFERENCE.
Lot number:
(TAKEN FROM CARTON)
_____________________________________
Date of purchase:
_______ / _______ / _______
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer
service department. We will replace the part FREE of
charge.
NEED HELP!
Tel #: 1-800-295-1980
CALL US FOR ASSISTANCE
E-Mail: das@dorel.com
1-800-295-1980
DO NOT RETURN PRODUCT T
Fax #: 514-353-7819
E-MAIL:DAS@DOREL.COM
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Dorel Asia Truly Scrumptious HEIDI KLUM
Summary of Contents for Dorel Asia Truly Scrumptious HEIDI KLUM
- Page 1 DOREL ASIA Model No: BR1330B4 (MIST) HEIDI KLUM UPC CODE: 4 IN 1 CRIB 0-65857-16638-5 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Lot number: (TAKEN FROM CARTON) _____________________________________ Date of purchase: _______ / _______ / _______ DO NOT RETURN PRODUCT TO THE STORE.
- Page 2 If you are missing parts or have any questions about this product, contact our customer service representative first! CALL 1-800-295-1980 You can also order parts by writing to the address listed below. Please include the product model number, color and a detailed description of the part. Customer Service Department No.
- Page 3 Check bolts/screws periodically and tighten them if necessary. LIMITED WARRANTY Dorel Asia warrants its product to be free from defects in material and workmanship and agrees to remedy any such defect. This warranty covers 1 year from the date of original purchase.
- Page 4 HEIDI KLUM 4 IN 1 CRIB BR1330B4 HARDWARE LIST Ø10 X 40mm Ø5/16" X 13mm X 1.5mmT WOOD DOWEL SPRING WASHER 16 PCS 18 PCS Ø1/4" X 15mm X80mm 4 X 74X 29mm BOLT ALLEN KEY 6 PCS 1 PC Ø1/4"...
-
Page 5: Parts List
HEIDI KLUM 4 IN 1 CRIB BR1330B4 PARTS LIST LEFT POST RIGHT POST FOOT 1 PC 1 PC 4 PCS HEADBOARD PANEL LEFT SIDE PANEL RIGHT SIDE PANEL 1 PC 1 PC 1 PC FRONT PANEL FRONT BOTTOM RAIL MATTRESS SUPPORT 1 PC 1 PC 1 PC... - Page 6 HEIDI KLUM 4 IN 1 CRIB BR1330B4 CRIB ASSEMBLY INSTRUCTION NOTE: When inserting bolts, turn clockwise until tight. Then loosen 1/2 - 3/4 of a turn. After crib is completely assembled, return to each bolt and tighten. Use wax or soap on all bolts to facilitate assembly.
- Page 7 HEIDI KLUM 4 IN 1 CRIB BR1330B4 STEP 1 Insert wood dowels (1) into front bottom rail (H). Attach the front bottom rail (H) to the front panel (G) with bolts (3) and spring washers (2). Use Allen Key(4) to tighten the bolts.
- Page 8 HEIDI KLUM 4 IN 1 CRIB BR1330B4 STEP 2 Insert wood dowels (1) into front panel (G). Attach feet (C ) to posts (A & B) by rotating clockwise. Attach left and right front posts (A & B) to front panel (G) and front bottom rail (H) with bolts (3), spring washers (2) using Allen key (4).
- Page 9 HEIDI KLUM 4 IN 1 CRIB BR1330B4 STEP 3 Insert wood dowels (1) into posts (A & B). Attach the left side panel (E ) and right side panel (F) to posts (A & B) as shown below with bolts (5) and spring washers (2). Use Allen key (4) to tighten all bolts (5).
- Page 10 HEIDI KLUM 4 IN 1 CRIB BR1330B4 STEP 4 Attach mattress support (I) to the posts with mattress support bolts (3) and spring washers (7). Use Allen key (4) to tighten the bolts (6). INCORRECT- Raised edge should face down -this photo shows mattress support is...
- Page 11 HEIDI KLUM 4 IN 1 CRIB BR1330B4 STEP 5 Attach legs (C) to headboard panel (D) by rotating clockwise. Attach headboard (D) to the left and right side panels (E & F) with bolts (8), wood dowels (1), and spring washers (2) as shown. Use Allen key (4) to tighten all bolts (8).
- Page 12 HEIDI KLUM 4 IN 1 CRIB BR1330B4 WARNINGS: * ANY MATTRESS USED IN THIS CRIB MUST BE AT LEAST 27-1/4 INCHES BY 51-5/8 INCHES (69CM BY 131CM) WITH A MINIMUM THICKNESS OF 4 INCHES (10CM) BUT NOT EXCEEDING 6 INCHES (15CM). * The toddler bed or day bed is not intended for children under 15 months of age or over 50 lbs (22.7 kgs).
- Page 13 HEIDI KLUM 4 IN 1 CRIB BR1330B4 FULL SIZE BED ASSEMBLY INSTRUCTION (HEADBOARD ONLY) NOTE: FULL SIZE CONVERSION RAILS ARE NOT INCLUDED. DIAGRAMS ARE FOR REFERENCE ONLY. BED RAILS MAY DIFFER FROM ILLUSTRATION. PEMBROOKE 4 IN 1 CRIB STEP 1 Attach the full size conversion rails (not included) to the headboard (D) .
- Page 14 HEIDI KLUM 4 IN 1 CRIB BR1330B4 FULL SIZE BED ASSEMBLY INSTRUCTION (HEADBOARD AND FOOTBOARD) NOTE: FULL SIZE CONVERSION RAILS ARE NOT INCLUDED. DIAGRAMS ARE FOR REFERENCE ONLY. BED RAILS MAY DIFFER FROM ILLUSTRATION. PEMBROOKE 4 IN 1 CRIB STEP 1 Attach the full size conversion rails (not included) to headboard (D) and assembled footboard (A,B,G&H).
- Page 15 HEIDI KLUM 4 IN 1 CRIB BR1330B4 CAUTION: This unit is intended for use only with the products and/or maximum weights indicated. Use with other products and/or products heavier than the maximum weights indicated may result in instability or cause possible injury. ANY MATTRESS USED IN THIS CRIB MUST BE AT LEAST 27-1/4 INCHES BY 51-5/8 INCHES (69CM...
- Page 16 HEIDI KLUM 4 IN 1 CRIB BR1330B4 Convert your crib into a toddler bed with the Heidi Klum Toddler Bed Conversion kit (model numbers BR1330-5) sold separately on www.toyrus.com.
- Page 17 HEIDI KLUM 4 IN 1 CRIB BR1330B4 Convert your crib into a full size bed with the Heidi Klum Wooden Side Rail & Slats set (model number BR1330-8) sold separately on www.toyrus.com.
- Page 18 MODEL #: BR1330B4 Customer Service PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S). Customer Service Phone Number 1-800-295-1980 Email: das@dorel.com Customer Service Fax Number 514-353-7819 Request Date: Name: Shipping Address:...
