APPLIANCE ACCESSORY FEATURES
JUG COVER CAP
The cup ⑧ has a scale for measuring small
quanti ti es of food ingredients. The scale
indicates 30ml and 60ml. When put on the jug
cover, it protects against splashing.
JUG AND JUG COVER
In jug bott om there is a hole for installing
the cutt er assembly ⑫. There are horizontal
lines on the outside of the jug that indicate
the following capaciti es: from 250 ml (MIN),
to 2000 ml (MAX). The jug is equipped with
a handle for easy carrying. The jug cover ⑥
has a gasket to ensure a good seal during
ASSEMBLING AND DISASSEMBLING THE BLENDER JUG
In order to install the stainless steel cutt er ⑫
perform the following operati ons:
1. Place the cutt er ⑫ in the jug bott om hole
and the seati ng ring ⑬ and fi t the recesses
in the cutt er head ⑫ to the jug base.
2. Holding the upper part of the cutt er ⑫,
turn the blender jug ④ so that the base
opening is pointed upwards.
3. Put seal ⑪ onto the jug base ring ⑩ so that
the fi t the external groove.
4. Put the jug base ring ⑩ onto the seal and
cutt er, and turn it clockwise while ensuring
that the thread is aligned properly.
5. To disassemble the blender cutt er, follow
the above steps in the reverse order.
To disassemble the blender knife reverse the
assembly procedure.
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
operati on. Ingredients can be added gradually
using the hole in the cover. The jug is equipped
with a safety lock that prevents the appliance
against incorrect fi tti ng.
DOME
The appliance is equipped with a dome with
a handle that allows you to reduce the noise
while mixing.
CUTTER ASSEMBLY
A cutt er assembly ⑨ is designed to provide
superior performance. It is made of stainless
steel. The set comprises also seals ⑪, ⑬ and
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
CAUTION! The blades are very sharp. Handle
with care! Always hold the blade by its upper
secti on!
CAUTION! The seals must fi t exactly to the
cutt er and the ring of jug base. Failure to use
the seals may result in leakage of the product
being processed and damage the appliance.
Correct assembly of the assembly guarantees
safe use and durability.
Before each assembly of the appliance, ensure
that all the components are in good conditi on
are not cracked or broken.
the jug base ring ⑩ that ensures a perfect seal
between the cutt er and the jug bott om.
PUSHER
The appliance is equipped with pusher ⑦, that
can be used for the preparati on of dense con-
sistency dishes e.g.: desserts, vegetable rupee
etc.. The pusher enables moving the com-
ponents towards the blades. The pusher can
move up and down, can be rotated or moved
to one side or to the corner of the blender jug.
CAUTION! To avoid contact of the pusher
with blender blades, use the pusher only
when cover ⑥ is properly placed.
CONTROL PANEL AND DISPLAY
The appliance features an electronic control
panel with a display ⑭ and touch butt ons with
sound signals.
A. POWER The power on/off switch
B. MENU Butt on for selecti ng one of 6 pro-
grams.
� VEGETABLES: Select this program to
process fruits and vegetables, speed
starts from 1 to H within 5 seconds
and the appliance starts to operate at
maximum speed for 2 minutes.
� SOYABEEN DRINK: Select this program
to process soya beans, speed starts from
1 up to 5 within 5 seconds, and then
the appliance is running at the speed
