E
DGE
Hardware Guide
1
Package Contents
1. EWS-100 unit
2. Antennas (2)
3. Ethernet cable (6 feet)
4. Power supply and cable (6 feet)
2
2
Connect the Antennas
Attach both antennas to the unit. Do not
apply excessive force when screwing on
the antennas—just finger tight.
Note: Use only the supplied antennas
with this product. Use of any other
antennas may damage the product, may
violate local regulatory requirements, and
will void the warranty.
I f you en coun ter p ro bl e ms wh en i nst alli ng thi s p ro du c t, con tact yo ur ser v ice pr ov ider.
W
IRELESS
3
S
(EWS-100)
YSTEM
This wireless network device has been tested and found
to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
wireless network device generates, uses, and radiates
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. For technical
support, consult your Service Provider.
4
3
Position the Antennas
Adjust both antennas to the upright
position until they snap into place.
210-1036-01
1
