Operation
Interior Texture Sprayer TS900
For use with water based materials only. For professional use only.
Not approved to European explosive atmosphere requirements.
24F566
60 psi (.41 MPa, 4.1 bar) Maximum Fluid Working Pressure
Important Safety Instructions
Read all warnings and instructions in this
manual. Save these instructions.
Related Manuals
311969
3A1171
3A1169A
ENG
ti9993a

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TS900 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AIRLESSCO TS900

Summary of Contents for AIRLESSCO TS900

  • Page 1 Operation 3A1169A Interior Texture Sprayer TS900 For use with water based materials only. For professional use only. Not approved to European explosive atmosphere requirements. 24F566 60 psi (.41 MPa, 4.1 bar) Maximum Fluid Working Pressure Important Safety Instructions Read all warnings and instructions in this manual.
