- Page 1 2U Rackmount Rail Slider Rail Slider for 2U Components Instruction Sheet I-00888 Rev A...
- Page 2 Important Safety Instructions Heed all warnings. • Read these instructions. • • Clean only with dry cloth. Keep these instructions. Follow all instructions. Only use attachments/accessories specified by the • • • manufacturer. WARNING: A warning alerts you to a situation that could result in serious personal injury or death. WARNING: Middle Atlantic Products, Inc.
- Page 3 Use mounting brackets and screws (provided in UPS packaging) to assemble the ears onto the sides of your UPS as shown. Installing 2U Rail Sliders Using Cage Nuts and Screws Step 1 Firmly insert fixing studs (A) on top set of holes on the rail sliders (B) as shown. Pull apart the ends of the rail sliders (B) to meet the depth of the rack chassis and force fixing studs (A) into the corresponding holes on the rack chassis columns.
- Page 4 Step 2 Use (4x) M6 rack screws (C) through the lower set of holes on the rail sliders (B) and into the rack chassis columns as shown. Step 3 Use (6x) cage nuts (D) in the proper location on the rack chassis columns based on your UPS height as shown.
- Page 5 Installing 2U Rail Sliders Using Rack Screws Step 1 Pull apart the ends of the rail sliders (B) so they align with the outside of the rack chassis columns. Step 2 Use (8x) M6 rack screws (C) through the holes on the rail sliders (B) and into the rack chassis columns as shown.
- Page 6 Step 4 Use (4x) rack screws (C) through the mounting brackets and into the front rack chassis columns as shown. Mounting Brackets...
