R
EMOVING THE OVEN DOOR
2.
Hold oven door so that the top edge of each
hinge hanger is horizontal. Insert hinge hangers
into the front frame hinge slots.
3.
Tilt top of door toward range. Slide hinge
hangers down onto front frame support pins.
NOTE: Make sure the hinge hangers are fully seated
and engaged on the support pins.
4.
Insert the door stop clip with the angular surface
at the top of the frame hinge slot, then push in
the bottom of the clip until flanges are flush with
the front frame.
5.
Open the door completely and remove the door
removal pins. Save door removal pins for future
use.
6.
Close the door.
T
HE OVEN LIGHT
The oven light will come on when you open the
oven door.
To turn the light on or off when the oven door
is closed:
Press the oven LIGHT pad.
To replace the oven light:
1.
Unplug range or disconnect power.
2.
Remove the glass bulb cover in the back of the
3.
Remove the light bulb from its socket. Replace
the bulb with a 40-watt appliance bulb.
.
( CONT
)
LIGHT
oven by turning it
counterclockwise.
Door stop
clip
Door removal
pin hole
Door removal
pin hole
4.
Replace the light bulb cover by turning it clockwise.
5.
Plug in range or reconnect power.
NOTE: The oven light will not work during the
Self-Cleaning cycle.
CARING FOR YOUR RANGE
Range
Hinge
hanger
Support pins
Front frame
hinge slot
Angular
surface of
door stop
clip
33
