Johnson Controls GVA Series Start-Up & Operation page 110

5586996-JSG-A-0120 | Start-Up & Operation Guide
Table 32: BACnet Points List (Continued)
BACnet
Object
Attributes Type
COMP2-A MV
COMP1-LO MV
COMP2-LO MV
LPS1 MV
LPS2 MV
LPS1-LO MV
LPS2-LO MV
Htg-En MV
Htg-S MV
FSHW MV
HtgUnocc-En MV
VAV Box MV
H1 MV
H2 MV
H3 MV
H1-S MV
H2-S MV
110
Object Read/
Short Description
ID Write
29640 R COMP2-A
29643 R COMP1-LO
29644 R COMP2-LO
29647 R LPS1
29648 R LPS2
29651 R LPS1-LO
29652 R LPS2-LO
29707 R/W Htg-En
29708 R Htg-S
29712 R Water FS
29724 R/W HtgUnocc-En
29727 R VAV Box
29732 R H1
29733 R H2
29734 R H3
29735 R H1-S
29736 R H2-S
Long
Point Definitions (Units)
Description
Compressor Displays the status of CKT 2 safety
Safety Chain 2 chain 0 = normal 1 = alarm
Compressor Displays the status of CKT 1 safety
Safety Chain chain lockout
Lockout 1 0 = normal 1 = lockout
Compressor Displays the status of CKT 2 safety
Safety Chain chain lockout
Lockout 2 0 = normal 1 = lockout
Low Pressure Displays the low pressure system 1
Safety 1 safety alarm 0 = normal 1 = alarm
Low Pressure Displays the low pressure system 2
Safety 2 safety alarm 0 = normal 1 = alarm
Displays the low pressure system 1
Low Pressure
safety lockout
Lockout 1
0 = normal 1 = lockout
Displays the low pressure system 2
Low Pressure
safety lockout
Lockout 2
0 = normal 1 = lockout
Heating Mode A BAS command that allows the unit
Enabled For to be placed in a heating mode
Operation 0 = OFF 1 = ON
Displays the active heating status
0 = OFF/idle
Heating Status 1 = ON
2 = SAT tempering
3 = morning warm-up
Displays the status of low
Low Temp Water
temperature water coil freezestat
Coil Freeze Stat
0 = normal 1 = alarm
Unoccupied A BAS command to enable UNOCC
Heating Enabled heating 0 = NO 1 = YES
MZ VAV Box Heat Displays the command of MZVAV
Command box heat 0 = OFF 1 = ON
Heating Stage Displays the command of heating
Command 1 stage 1 0 = OFF 1 = ON
Heating Stage Displays the command of heating
Command 2 stage 2 0 = OFF 1 = ON
Heating Stage Displays the command of heating
Command 3 stage 3 0 = OFF 1 = ON
Displays the status of heating stage 1
0 = OFF/idle
Heating Stage 1
1 = ON/minimum runtime timer
Status
2 = ON/normal command
3 = OFF/heating is disabled
Displays the status of heating stage 2
0 = OFF/idle
Heating Stage 2
1 = ON/minimum runtime timer
Status
2 = ON/normal command
3 = OFF/heating is disabled
