Johnson Controls GVA Series Start-Up & Operation page 105

Table 32: BACnet Points List (Continued)
BACnet
Object
Attributes Type
HE-T AV
HighSpeedFan-
AV
MinPos
HRW-O AV
HtgCapLim AV
HtgDATLo-SP AV
HtgDATUp-SP AV
Hum-SP AV
ModCompOut AV
ModCondFan1Out AV
ModCondFan2Out AV
ModHtgOut AV
OprHtgDAT-SP AV
PFILT-DP AV
RAD-O AV
RAD-POS AV
RunContAlmDly AV
SF-DAT-
AV
SpHighThresh
SF-DAT-
AV
SpLowThresh
SZVAVClgMinFan AV
Johnson Controls
Object Read/
Short Description
ID Write
30004 R HE-T
HighSpeedFan-
30006 R/W
MinPos
30008 R HRW-O
30010 R/W HtgCapLim
30011 R/W HtgDATLo-SP
30012 R/W HtgDATUp-SP
30014 R/W Hum-SP
30017 R ModCompOut
30018 R ModCondFan1Out
30019 R ModCondFan2Out
30020 R ModHtgOut
30021 R OprHtgDAT-SP
30022 R PFILT-DP
30025 R RAD-O
30026 R RAD-POS
30028 R/W RunContAlmDly
SF-DAT-
30029 R/W
SpHighThresh
SF-DAT-
30030 R/W
SpLowThresh
30034 R/W SZVAVClgMinFan
Start-Up & Operation Guide | 5586996-JSG-A-0120
Long
Point Definitions (Units)
Description
Heat Entering Displays the active heat entering
Temperature temperature (°F)
Economizer
A BAS command to adjust outside
Damper Minimum
air damper minimum position for high
Position High
speed fan (0–100%)
Speed Fan
Heat Recovery
Displays the ERW control output (%)
Wheel Output
Heating Capacity A BAS command to adjust the
Limit heating capacity limit (0–100%)
Heating DAT A BAS command to adjust heating
Lower Setpoint DAT lower setpoint (85.0–134.0°F)
Heating DAT A BAS command to adjust heating
Upper Setpoint DAT upper setpoint (85.0–134.0°F)
Humidification A BAS command to adjust
Setpoint humidification setpoint (0–100 %RH)
Modulating
Displays the active modulating
Compressor
compressor value (0–100%)
Output
Modulating
Displays the active modulating
Condenser Fan 1
condenser fan 1 value (0–100%)
Output
Modulating
Displays the active modulating
Condenser Fan 2
condenser fan 2 value (0–100%)
Output
Modulating Heat Displays the active modulating heat
Output value (0–100%)
Operating Heating Displays the active heating DAT
DAT Setpoint setpoint (°F)
Pre-Filter
Displays the differential pressure for
Differential
first filters (pre-evap) (iwg)
Pressure
Return Air
Displays the status of return air
Damper
damper command (%)
Command
Return Air Displays the status of return air
Damper Position damper position (%)
Unit Running A BAS command that adjusts unit
Continuously running continuously alarm delay
Alarm Delay (1–99 hours)
Supply Fan DAT A BAS command to adjust DAT
Setpoint High based on high supply fan speed
Threshold (0–100%)
Supply Fan DAT A BAS command to adjust DAT
Setpoint Low based on low supply fan speed
Threshold (0–100%)
SZVAV Cooling
A BAS command to adjust SZVAV
Minimum Fan
cooling minimum fan speed (20–67%)
Speed
105
