Pre Start-Up Checklist - Johnson Controls GVA Series Start-Up & Operation

NEW RELEASE
Date: ______________
Job Name: ______________________________________
Order No.: ______________________________________
Contract No.: ____________________________________
Serial No.: ______________________________________
Model No.: ___________________________________________________________________________________________
Installation Completion Date: ________________________
In an effort to provide the highest level of service, the following checklist is provided to ensure that all necessary installation
items are completed prior to a scheduled supervised start-up for the rooftop unit. Refer to the appropriate Installation and Main-
tenance Manual (Form 5586959-JIM) before evaluating the information on this Checklist. E-mail the completed checklist to
cg-upgtechsupport@jci.com.
NOTE: Check off each item as required. Cross out (x) items that do not apply.
1. Unit inspected for shipping, storage, or rigging damage ............................................................
2. Unit installed with proper clearances..........................................................................................
3. Unit installed with slope limitations .............................................................................................
4. Ductwork is completed and cleared of all obstructions ..............................................................
5. All field wiring (power and control) is complete (matching the nameplate) ................................
6. The building automation system (BAS) is connected to the unit and operational (if applicable)
7. Variable air volume (VAV) units:
a. The VAV boxes are verified as operational ................................................................................
b. Discharge air static pressure transducer tubing is installed in the appropriate location ........
8. Single zone VAV (SZVAV) units (check whichever option is applicable):
a. A NetSensor is connected to the SA bus on the main control board ....................................
b. The BAS is communicating a zone temperature to the unit ..................................................
9. Exhaust/return fan units:
a. Building static pressure transducer tubing is installed in the appropriate location ...................
10. When either of the discharge air static or building static pressure transducers are installed, an
outdoor pressure reference is also field installed via the shipped loose kit ..................................
11. Condensate drain is installed and trapped properly ...................................................................
12. Gas heat units:
a. The gas line is installed per local codes and purged of air ...................................................
b. The incoming gas pressure is within the range specified on the unit nameplate ..................
13. Hot water/steam units:
a. Field piping to the hot water/steam coil is completed ..............................................................
b. The shipped loose modulating valve is installed and field wiring to the valve is completed .....
Johnson Controls
Johnson Controls

Pre Start-Up Checklist

Customer: ____________________________________
General Inspection
Start-Up & Operation Guide | 5586996-JSG-A-0120
Premier Rooftop Units
®
Phone No: ___________________
Job Address: _______________________________________
City: _______________________________________
State: ______________
Country: _______________________________________
Requested Start-Up Date: _____________________________
Form 5773246-JCL-A-619
25–50 Tons
R-410A
Zip Code: _____________
Completed See Notes
7
