UNI-BUG BULB FLAT WELDER

UNI-BUG Bulb Flat Welder will weld large bulb angles from 140-430 mm
Dimensions of machine
without torch mounts.
(Torch mounts shown on
earlier pages).
The UNI-1305, Bulb
Flat Welder Adaptor
Kit can be used with
the standard UNI-BUG
for bulb flat welding.
16
(159 mm)
10.50
(267 mm)
6.00
(152 mm)
2.00
(51 mm)
4.6
(117 mm)
*Spacer Block For 280 to 430 mm
7.62
(194 mm)
6.25
5.75
(146 mm)
8.00
(203 mm)
