programming
Important Note: It is important to select the correct DIP switch position based on BOTH the model (first column) and the pipe
size (second column) shown in the table below.
FlowVis Model
FV-C; FV-C-L; FV-C-M-DN50
FV-C-S; FV-C-S-L
FV-C; FV-C-L; FV-C-M-DN65
FV-C-S; FV-C-S-L
FV-C-M-DN65-HF-S
FV-3; FV-3-L; FV-C-M-DN80
FV-4; FV-4-L; FV-C-M-DN100
FV-6; FV-6-L; FV-C-M-DN150
FV-8; FV-8-L; FV-C-M-DN200
FV-C-15; FV-C-M-DN40
operation
After setting the DIP Switches to reflect the FlowVis model and Pipe Size employed in your application, the FlowVis Digital
is ready to use. No calibration or further settings are required. However, by default, the FlowVis Digital readout will display
the flow rate in US GPM and the Turnover Rate will show --- (indicating that this function is not activated). If you would like to
change the unit of measurement from US GPM to either LPM or m3/hr, and /or activate the pool Turnover Rate function, then it
will be necessary to access these functions as described in the Advanced Setup section.
www.h2flow.net • Tel: 888-635-0296 (Toll Free)
Fig 2.9 (left) The
default setting for
the DIP switches (all
switches set to the
OFF position).
Pipe Size
1
2" and DN50
ON
2"
ON
2.5"
ON
2.5"
ON
DN65
OFF
3" and DN80
OFF
4" and DN100
OFF
6" and DN150
OFF
8" and DN200
OFF
1.5" and DN40
OFF
8
(+1) 419-841-7774 (International)
OR
DIP Switch Position
2
3
OFF
OFF
ON
OFF
ON
ON
ON
ON
ON
OFF
OFF
ON
OFF
OFF
ON
OFF
ON
ON
ON
ON
Fig 3.0 (left) DIP
switch number 1 set
to the ON position.
4
OFF
OFF
OFF
ON
OFF
OFF
ON
ON
OFF
ON
