4 Intended use
Control device for operating and monitoring a pump in domestic water supply. The
device is screwed onto the discharge side of the pump or into the discharge pipe.
It allows fully automatic operation without a diaphragm expansion tank.
5 Product information
5.1 Technical data
Hydraulic data
Fluid
Maximum flow rate
Maximum operating pressure
Connection diameter
Temperature range
Max. fluid temperature
Electrical data
Protection class
Max. current
Voltage
Frequency
Technical information
Start-up pressure
5.2 Dimensions
Fig. 6: Lateral view – frontal view
5.3 Description of the product (Fig. 1, 2 and 5)
1 - Suction port with integrated non-return valve
2 - Pressure port
3 - Control pressure gauge (0 – 10 bar),
installation is possible on the right or on the left
4 - Electrical box with circuit board including dry-running protection by deactiva-
tion of the motor, electrical connection of the pump and mains connection
5 - Hydraulic chamber with membrane
6 - Compensation chamber with spring
7 - Adjusting screw for pump start-up pressure
8 - RESET key
9 - Voltage control lamp
10- Pump operation control lamp
11- Safety system control lamp
12- Pressure gauge axle
Installation and operating instructions - Wilo-HiControl 1/FC
Clear water without solid particles
10 m³/h
10 bar
R1"
+60 °C
IP65
16 A
Single-phase 220/250 V
50/60 Hz
1.5 bar to 2.7 bar
