Welcome to the passion people
techtip 1, May 2012
How to reroute and shorten the hose without bleeding the brake
Before you start turn the master vertically upwards
Attention: If possible, FIRST cut the hose about 150mm from the master.
Then use an 8mm open spanner and remove first the sleeve nut and then the hose.
To avoid spillage hold the hose!
Attention: if the hose is routed through the frame, take care to shorten it AFTER routing through the frame.
In case of routing the hose through the frame, please order the hose with an additional length of 300mm.
If possible use a plug to close the hose during the routing process.
Take the hose after routing through the frame and check for correct length before shortening it.
Tighten the sleeve nut with the correct torque of 4Nm while HOLDING the hose.
Advertisement
Related Manuals for Magura MT Series
Summary of Contents for Magura MT Series
- Page 1 Welcome to the passion people techtip 1, May 2012 How to reroute and shorten the hose without bleeding the brake Before you start turn the master vertically upwards Attention: If possible, FIRST cut the hose about 150mm from the master. Then use an 8mm open spanner and remove first the sleeve nut and then the hose.
- Page 2 Hose routing MAGURA MT brakes offer you perfect hose routing options. Loosen the banjo bolt with a Torx T25 key by turning max. 30° counter clockwise. Turning beyond 30° may introduce air into the system. Now turn and adjust the hose to the required angle.
