Wilo Control SC-Booster Installation And Operating Instructions Manual page 94

Valid until Display
SCe
SC...FC
SCe
SC...FC
4.1.3.1
to
4.1.3.4
SCe NWB
SCe NWB
4.1.4.1
to
4.1.4.4
SCe NWB
Installation and operating instructions Wilo-Control SC-Booster (SC, SC-FC, SCe)
Description
Operating values
Actual value of the output pressure of the system
Active setpoint
The menu with the current pump speeds
The current speed for pump 1,2,3,4. Pages are only
displayed for pumps that are installed in the system.
The menu for the current power consumption of the
single pumps
Current power consumption of pumps 1 – 4. Pages
are only displayed for pumps that are installed in the
system.
The current supply pressure on the supply line
English
Parameter range
Factory setting
23
