English
Valid until Display
SCe NWB
SCe NWB
32
Description
The absolute minimum pressure on the outlet side.
This value is automatically calculated based on the
relative minimum pressure and the current setpoint.
Behaviour in the event of minimum pressure
Delay maximum pressure signal
Delay minimum pressure signal
The threshold for detecting a dry run via the supply
pressure sensor. If the threshold is greater than the
threshold in menu 5.4.7.0., the 5.4.7.0. threshold is
set to the value of this threshold.
The threshold for resetting after a dry run is
detected via the supply pressure sensor. The
threshold must be greater or equal to the 5.4.6.0.
threshold. If the threshold is smaller than the
threshold in menu 5.4.6.0., the 5.4.6.0. threshold
is set to the value of this threshold.
Signal output parameters
The behaviour of the collective run signal
Parameter range
Factory setting
OFF (Stop)
ON (Cont)
0 ... 20 ... 60
0 ... 20 ... 60
-1.0 ... 1.2 ... sensor
measurement range
-1.0 ... 1.5 ... sensor
measurement range
Ready
Run
