- Page 1 Altus Manual AUTOMATIC CALIBRATION MODE Inspired by life...
- Page 2 EvO Altus uses theses actuators: negative tilt actuator REAC RE 3005 150mm throw 6000N 0 – 10 Kohm potentiometer Wiring of each actuator of EvO Altus......................3 tilting actuator REAC RE 3005 150mm throw 6000N 0 – 10 Kohm potentiometer...
- Page 3 Inspired by life 2. Wiring of the support wheel switches legrest actuator (RE25) 2.1. Version V01.01 (first batch 05-2017) Inh.25 Inh.24 inhibbit connection motor connection Support wheels actuator (RE25) Inh.27 Inh.26 Inh.27 Inh.26 motor connection inhibbit connection 2.2. Version V01.02 (from 30-08-2017) Inh.32 6.
- Page 4 3. Programming the EvO Altus V01.0.1 Step 3: load configuration To prepare the EvO Altus for delivery the next steps have to be executed: 1. Programming the flash of the CSXM 2. Uploading the Default files of R-net EvO Altus 3.
- Page 5 Inspired by life 4. Uploading R-net Default files Step 6: programming in action Upload the R-net OEM files to the wheelchair using R-net OEM software and dongle. Step 7: programming flash finished!! WARNING WARNING don’t switch off the chairs whilst programming the flash. By uploading this file, not all parameters are properly set! Therefore we now need to open the CxSM developer software and open and write the R-net file once more.
- Page 6 To enter the automatic calibration mode you need to use the Calibration key tool. This tool is only available from NOTE Karma Directly and is only to be used by trained and authorized persons. make sure you push the switch until the normal driving screen has been shown. letting go too early or holding this special key need to connected to the CxSM module, using Inhibit 7 port.
- Page 7 Inspired by life 6. Error codes for EvO Altus: 7. Fine tune adjustments EvO Altus The R-net system has been equipped with additional Altus error codes. To set the standing height and standing angle we can use: 6.1. failure calibration procedure...
- Page 8 Inspired by life 7.5. To avoid crashing the legrest at low seat height: To avoid crashing the legrest into the ground at low seat height and 90 degrees legrest, one could activate a drive inhibit/ low drive speed at the tilt inhibit. Drive inhibit 20, band 0 is on default 100% speed, but can be changed to 0% (drive inhibit) or 10% (very low speed) setting of the speed inhibit on low seat height and flat seat angle.
- Page 9 Life & Mobility bv PO Box 304 NL - 7000 AH Doetinchem Tel.: +31 (0)314 328 000 Logistiekweg 7 www.life-mobility.com info@life-mobility.com 7007 CJ Doetinchem...
