WARNING
USER DRIVEN MANUAL*
Read all instructions before beginning installation
Any feedback, changes, or advice we are glad
or use of this gate opener.
to hear it. Please contact us at
This operator excerts a high level of force.
support@estateswing.com
Excercise caution at all times and stay clear of the
system during operation.
E
S
.
STATE
WING
COM
E-SC 400 / 402 Classic Series
INSTRUCTION MANUAL
*Estate Swing's unique user driven manuals are constantly updated by installers and homeowners like yourself. We improve by hearing and applying your feedback.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Classic Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Estate Swing Classic Series

Summary of Contents for Estate Swing Classic Series

  • Page 1 Excercise caution at all times and stay clear of the system during operation. STATE WING E-SC 400 / 402 Classic Series INSTRUCTION MANUAL *Estate Swing’s unique user driven manuals are constantly updated by installers and homeowners like yourself. We improve by hearing and applying your feedback.
  • Page 2 Estate Swing Summary of Functions e Estate Swing is only to be used for vehicular swing gates in a Class I setting. A vehicular gate opener (or system) intended for use in a home of one- Class I: to-four single family dwelling, or a garage or parking area associated therewith.

  • Page 3: Table Of Contents

    Temporary Safety Jumpers & Dip Switch Settings Power Section 4: Start Up and Operation Find Limit Position First Run Operating Parameters Customization 433 Plug-in Receiver 4.4-.5 Section 5: Troubleshooting & Accessories Troubleshooting 5.1-.3 Control Board Overview 5.4-.7 Accessories E-SC 400/ 402 Classic Series Instruction Manual...

  • Page 4: Section 1: Review Of Specifications, Warnings, And Tools

    Section 1: Review of Specifications, Warnings, and Tools...
  • Page 6 E-SC 400/ 402 Classic Series Instruction Manual...

  • Page 7: Parts List

    D. Articulating Arms E. Gate Bracket E. Gate Bracket F. Transformer F. N/A G. Manual Release G. Manual Release Not Shown: Not Shown: Motor Bolts Remote / Transmitter Mount Bolts Mount Bolts Receiver Motor Bolts E-SC 400/ 402 Classic Series Instruction Manual...
  • Page 8 10’ in length. Make sure the gate is plumb and level. e fence post must be secured in the ground with concrete. is will prevent alteration of alignments and leveling during installation and during cycles. E-SC 400/ 402 Classic Series Instruction Manual...

  • Page 9: Tools Needed For Installation

    Base Plate to the column. 2 - 5/16” Hex Bolts will be needed to connect the Gate Mounting Bracket to the gate Electrical boxes or plug covers E-SC 400/ 402 Classic Series Instruction Manual...
  • Page 10 Section 2: Manual Operation & Installation...
  • Page 12 To avoid an involuntary pulse activating the gates during the maneuver, switch off all power before re-locking the operator. Fit the supplied release key in the hole and turn it until the key springs back to its original position. E-SC 400/ 402 Classic Series Instruction Manual...
  • Page 13 22” Large 11” - 13” (4” - 6” column*) 3” 16” Small e A measurement shown above shows the ranged measurements for the setback. e measurments for B and C, however, are constant. E-SC 400/ 402 Classic Series Instruction Manual...

  • Page 14: Section 2: Installation

    4) Check to make sure you have clearance for your motor from the face of the column. You must have at minimum of 7 inches from the face of the column to the drive shaft of the motor. E-SC 400/ 402 Classic Series Instruction Manual...
  • Page 15 1/2 inch masonry bit. If using the provided anchor bolts, drill the holes using a 15 mm masonry bit. 8) Using the provided long bolts, attach the rear of the motor to the bracket. E-SC 400/ 402 Classic Series Instruction Manual...
  • Page 16 1/2” 12) Insert the 1/4” x 1 carriage bolt through the straight motor arm so the square head fits into the square hole of the arm. E-SC 400/ 402 Classic Series Instruction Manual...
  • Page 17 15) Attach the motor arms to the bottom of the motor using the provided bolt. E-SC 400/ 402 Classic Series Instruction Manual...
  • Page 18 Section 3: Wiring, Jumpers & Receiver...

  • Page 20: Control Box & Running Wires

    Wiring: It is important that all wires are constricted into water tight connector. Connecting wires for the slave operator (if applicable): E-SC 400/ 402 Classic Series Instruction Manual...

  • Page 21: Easy Wiring Under Driveway

    6 inches of pipe is sticking out from up to 24’ in width. under the driveway. On the opposite side of the driveway look for a wet spot or water bubbling up, dig to find the end of the pipe. E-SC 400/ 402 Classic Series Instruction Manual...
  • Page 22 Be sure not to mistake this for open and insert the wires below the terminal clamp. is will lack the conductivity to complete the circuit. E-SC 400/ 402 Classic Series Instruction Manual...
  • Page 23 Limit CL terminal on motor to Limit 2 - CL2 terminal Limit COM terminal on motor to Limit 2 - V+ terminal Limit OL terminal on motor to Limit 2 - OL2 terminal E-SC 400/ 402 Classic Series Instruction Manual...

  • Page 24: Temporary Safety Jumpers & Dip Switch Settings

    IMPORTANT: We recommend before turning the gate opener on for the first time, to have dip switch 1 OFF. If the dip switch is set on, the gate will autoreclose after turning it on without any intentional activation on your part. E-SC 400/ 402 Classic Series Instruction Manual...

  • Page 25: Power

    DO NOT SPLICE THE POWER CABLE WIRE. Never run 110VAC power directly to the Estate Swing. is will destroy the Estate Swing control board. Never connect the power wire with the transformer plugged in. Contact between the two lead wires, even for a second, will destroy the transformer.

  • Page 26: Section 4: Start Up And Operation

    Section 4: Start Up and Operation...
  • Page 28 3) Move the doors open and repeat the above step with the limit trip that triggers the bottom limit switch. Closed Limit Turn to Move Open Limit Turn to Lock/Unlock E-SC 400/ 402 Classic Series Instruction Manual...

  • Page 29: First Run

    Manually unlock the gate, then move it half-way and re-engage. Activate using Push 1 button (as shown above) e gate should run open. Press Push 1 again and it should run closed. e gate is now set up for regular use. E-SC 400/ 402 Classic Series Instruction Manual...

  • Page 30: Operating Parameters Customization

    6. LED shows P6: P6 is the release for the gate lock – this option determines the length of time 24VDC will be sent out of terminals E_LOCK. e options are 1-4 seconds. E-SC 400/ 402 Classic Series Instruction Manual...

  • Page 31: 433 Plug-In Receiver

    Leave this jumper wire in place. One of the terminals that has the jumper wire will have the White wire added to the terminal. Green = CH1 White = CH1 Red=V+ E-SC 400/ 402 Classic Series Instruction Manual...
  • Page 32 DO NOT mount the receiver anyplace that water may access it from another angle. For example: Do not mount near sprinklers. Do not mount the receiver horizontally. Do not mount the receiver near a flat surface where water could splash upwards. E-SC 400/ 402 Classic Series Instruction Manual...
  • Page 33 Section 5: Troubleshooting and Accessories...

  • Page 35: Troubleshooting

    If the gate will open but will not close: e display of the board will not light up. If limit motor is opening or closing past the limits. E-SC 400/ 402 Classic Series Instruction Manual...
  • Page 36 Troubleshooting e gate opener is not stopping on the limit switches One or both arms are not moving General fix for user to understand operation. E-SC 400/ 402 Classic Series Instruction Manual...
  • Page 37 Below is an example of control board picture that we will be looking for: E-SC 400/ 402 Classic Series Instruction Manual...

  • Page 38: Control Board Overview

    Operational Sequence for terminal with autoclose OFF (Dip switch 1 in off position): what it was moving before stopped. E-SC 400/ 402 Classic Series Instruction Manual...
  • Page 39 PUSH 1 and PUSH 2 – these terminals can hold as many normally open connections as needed, they will be wired in parallel. ey are used for keypads, push buttons, universal receivers, etc. E-SC 400/ 402 Classic Series Instruction Manual...
  • Page 40 *PUSH 2 / V+ is for exit wand, exit loops or other open only dry contact and momen- tary contact Solenoid lock output -12VDC (4 Amp max) E_Lock: A = Positive B = Negative Fuses: F1 = 8A 250V, protects incoming power to board E-SC 400/ 402 Classic Series Instruction Manual...
  • Page 41 (transformer) and secondary power (back up batteries - if appli- cable). E-SC 400/ 402 Classic Series Instruction Manual...
  • Page 42 find at the above address may be written to coincide with that manufacturers model of gate opener. To determine correct terminals on your Estate Swing operator, use the accessory terminal section of your Estate Swing manual.
