―WARNING―
USER DRIVEN MANUAL*
Any feedback, changes, or advice we are glad
Read all instructions before beginning installation
or use of this gate opener.
to hear it. Please contact us at
This operator excerts a high level of force.
support@estateswing.com
Excercise caution at all times and stay clear of the
system during operation.
E
S
.
STATE
WING
COM
E-S 300 / 302 Classic Series
INSTRUCTION MANUAL
*Estate Swing's unique user driven manuals are constantly updated by installers and homeowners like yourself. We improve by hearing and applying your feedback.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Classic Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Estate Swing Classic Series

  • Page 1 Excercise caution at all times and stay clear of the system during operation. STATE WING E-S 300 / 302 Classic Series INSTRUCTION MANUAL *Estate Swing’s unique user driven manuals are constantly updated by installers and homeowners like yourself. We improve by hearing and applying your feedback.
  • Page 2 Estate Swing Summary of Functions The Estate Swing is only to be used for vehicular swing gates in a Class I setting. A vehicular gate opener (or system) intended for use in a home of one-to-four Class I: single family dwelling, or a garage or parking area associated therewith.
  • Page 3: Table Of Contents

    Temporary Safety Jumpers & Dip Switch Settings Power Section 4: Programming the Operator Adjust limit switches and determine run time 4.1-2 Operating Parameters Settings Section 5: Troubleshooting & Accessories Troubleshooting 5.1-.3 Control Board Overview 5.4-.7 Accessories E-S 300 / 302 Classic Series Instruction Manual...
  • Page 4 The above chart represents the maximum weight and length combinations that this gate opener can handle. The lengths and weights are either for a single gate or for a single leaf of a dual gate. E-S 300 / 302 Classic Series Instruction Manual...
  • Page 5: Parts List

    1 - 5/16”x 1 3/8” Hex bolt, washer, nut 1 - 1/4” x 2” Hex bolt, washers, nut 2 - 3/8”x 2” Carriage bolt, washers, nut 1 - 1/4” x 2” Hex bolt, washers, nut Not Shown: Additional Wire E-S 300 / 302 Classic Series Instruction Manual...
  • Page 6 Photo sensors and a flashing light indicating gate movement is recommended for safety purposes. 1,2 Estate Swing Operator • 3 Photocells (not included) • 4 Control board • 5 N/A 6 Push button opening device (not included) • 7 Receiver extension (not included) • 8 24Vdc flashing lamp (not included) •...
  • Page 7: Tools Needed For Installation

    Other items may be needed prior to commencing installation. BOLDED items are necessary to all applications. • Positive post, bracket or door stop. Although the Estate Swing 300 features built in limit switches it is highly recommended to have positive stops.
  • Page 8 3. Allow the lubricant to soak in. 4. Apply a liberal dab of petroleum based jelly or wheel bearing grease to coat the release lock. 5. Put the cap securely back in place. E-S 300 / 302 Classic Series Instruction Manual...
  • Page 9 To determine the position of the gate mounting bracket (above is for the post 5 ¼" 5 ¼" 10 1/2 100° mounting bracket) refer to step 6 in the section “Installation of operator” 5 ½" 5 ½" 90° E-S 300 / 302 Classic Series Instruction Manual...
  • Page 10: Installation Of Operator-Pull To Open

    4. Insert a 3/8” x 1” bolt in the center hole and a 5/16” bolt in the rear hole. Secure them using the provided nuts and lock washers. BEFORE PERMANENTLY ATTACHING ANY BRACKETS, BE SURE TO TEST ARM MOTION AND CLEARANCE. E-S 300 / 302 Classic Series Instruction Manual...
  • Page 11 “boomerang” shaped bracket to the center hole of the gate bracket – this should be the position of the gate bracket on the closed gate. 7. Attach the gate mounting bracket using carriage bolts, nuts, and washers. E-S 300 / 302 Classic Series Instruction Manual...
  • Page 12 2 inches away from the gate in both the open and closed position. (setback variations significantly reduces the length and weight capacity of the operator) E-S 300 / 302 Classic Series Instruction Manual...
  • Page 13: Installation Of Operator-Push To Open

    4. Insert a 3/8” x 1” bolt in the center hole and a 5/16” bolt in the rear hole. Secure them using the provided nuts and lock washers. BEFORE PERMANENTLY ATTACHING ANY BRACKETS, BE SURE TO TEST ARM MOTION AND CLEARANCE. E-S 300 / 302 Classic Series Instruction Manual...
  • Page 14 “boomerang” shaped bracket to the center hole of the gate bracket – this should be the position of the gate bracket on the closed gate. 7. Attach the gate mounting bracket using carriage bolts, nuts, and washers. E-S 300 / 302 Classic Series Instruction Manual...
  • Page 15 The terminals come closed. Be sure not to mistake this for open and insert the wires below the terminal clamp. This will lack the conductivity to complete the circuit. E-S 300 / 302 Classic Series Instruction Manual...
  • Page 16 If gaps exist in the rubber wire cap after feeding the wires through, seal with silicone. Pull to Open (Opening in towards property) It is important to choose the correct operation type Push to Open (Opening out towards the street) E-S 300 / 302 Classic Series Instruction Manual...
  • Page 17 9 dip switch Switches: positions in the remote located under the battery lid. Tip: If interferance is occuring, change dip switches to another random position on both remote and reciever. E-S 300 / 302 Classic Series Instruction Manual...
  • Page 18: Temporary Safety Jumpers & Dip Switch Settings

    1 OFF. If the dip switch is set to on, the gate will autoreclose after turning it on without any intentional activation on your part. E-S 300 / 302 Classic Series Instruction Manual...
  • Page 19: Power

    Power The Estate Swing E-S 300 comes with 1) 24V transformer. The transformer supplied has 2 screw terminals to connect to. You may locate the transformer up to 200’ away from the control board using 16 gauge, 2 conductor stranded direct burial low voltage wire.
  • Page 20 (as you open the gate you can leave the washer on the side and it will move along with the magnet). Example of washer and magnet in open position (closed for push-to-open) E-S 300 / 302 Classic Series Instruction Manual...
  • Page 21 On the display you will see a count while the arms are moving. This is your run time. Record your run time below. ACTUAL RUN TIME: _____________________________ E-S 300 / 302 Classic Series Instruction Manual...
  • Page 22 7. LED shows P6: P6 is the release for the gate lock – this option determines the length of time 24VDC will be sent out of terminals E_LOCK. The options are 1-4 seconds. 8. Press SET to finish. You should hear 3 beeps; this indicates parameter programming is finished. E-S 300 / 302 Classic Series Instruction Manual...
  • Page 23: Troubleshooting

    Example: If P2 is set to 14 and it takes 13 seconds to move from closed to open it will not enter slow down mode. Decrease this number. More on next page E-S 300 / 302 Classic Series Instruction Manual...
  • Page 24 The options are 0-9 seconds delay. E-S 300 / 302 Classic Series Instruction Manual...
  • Page 25 Below are examples of control board pictures and motor pictures that we will be looking for: we will be looking for: Pictures shown are actual customer photos E-S 300 / 302 Classic Series Instruction Manual E-S 300 / 302 Classic Series Instruction Manual...
  • Page 26: Control Board Overview

    6. When stopped mid cycle - momentary contact will open the gate. 7. When open with auto-reclose off - momentary contact will have no effect. 8. When closing - momentary contact will re-open the gate. E-S 300 / 302 Classic Series Instruction Manual...
  • Page 27 PUSH 1 and PUSH 2 – these terminals can hold as many normally open connections as needed, they will be wired in parallel. They are used for keypads, push buttons, universal receivers, etc. E-S 300 / 302 Classic Series Instruction Manual...
  • Page 28 300 milliamps. Do not attach accessories until after you have the gate opener limit switches and parameters set up and the gate opener functioning properly by remote. E-S 300 / 302 Classic Series Instruction Manual...
  • Page 29 At this point no accessories or remotes will be able to activate the gate opener until the gate opener is reset by disconnecting primary power (transformer) and secondary power (back up batteries - if applicable). E-S 300 / 302 Classic Series Instruction Manual...
  • Page 30 To determine correct terminals on your Estate Swing operator, use the accessory terminal section of your Estate Swing manual. The following are some common terms and abbreviations found in manuals: Normally Open –...
