  • Page 1 Instruction Manual for the E-S 1600/ E-S 1602 / E-S 1600L / E-S 1602L Series...
  • Page 2 Address: Via Benini, 1 – 40069 Zola Predosa Bologna – Italy Declares that: 409 A.K.A. Estate Swing (USA) mod operator Is built to be integrated into a machine or to be assembled with other machinery to create a machine under the provisions of Directive 89/392/EEC, and subsequent amendments 91/368/EEC, 93/44/EEC.

  • Page 3: Installation

    Estate Swing Summary of Functions The Estate Swing is only to be used for vehicular swing gates in a Class I setting. Class I: A vehicular gate opener (or system) intended for use in a home of one-to-four single family dwelling, or a garage or parking area associated therewith.

  • Page 4: Table Of Contents

    The table of contents are listed to assist you locating a desired section. We do howev- er strongly suggest studying every page of the instruction manual before attempting installation. SECTION: Review of specifications, warnings, and tools Specifications of the Estate Swing and Components Parts List System Overview & Preliminary Checks Tools Needed for Installation Installation...
  • Page 5 The table of contents are listed to assist you locating a desired section. We do howev- er strongly suggest studying every page of the instruction manual before attempting installation. SECTION: Diagnostics First Run & Parameters 5.1-.2 Plug-in Receiver 5.3-.4 Maintenance and Trouble Shooting Bracket Maintenance Troubleshooting 6.2-.5...
  • Page 6 MODEL Estate Swing Power Supply 115V AC/ 24V AC Rated Absorbed Power (W) Current (A) Travel (in.) Cycles per hour Continuous Duty / Aprox. 75 Operating Ambient Temp -4 to 131 F Protection class IP44 Up to 14 (L-series: up to 20) Gate leaf max length (ft.)
  • Page 7 Primary or Single Operator Secondary Operator (If Applicable) B. Operator Arm with 33' (45') A. Control Box B. Operator Arm with 6' of 5 Conductor Wire and of 5 Conductor Wire G. Gate Mounting Bracket C. Control Board H. Post Mounting Brackets D.

  • Page 8: Preliminary Checks

    1,2 Estate Swing Operator Standard System 3 Photocells (not included) 4 Control board Overview and Safety Zones 5 N/A 6 Push button opening device (not included) 7 Receiver extension (not included) The system display to the below is a 8 12Vdc flashing lamp (not included) recom-mended standard system.

  • Page 9: Diagnostics

    Other items that may be needed prior to commencing installation. Bolded items are necessary to all applications. Start and stop post, bracket or door stop. Although the FAAC Estate swing 1600 features built in limit switches some may choose to use positive stops: 16, 14 or 12 gauge, 2 conductor stranded direct burial low voltage wire will be required to run power to your operator.
  • Page 10 Manual Operation Mode 2) Remove rubber cover 3) Insert key and turn it 90 degrees. 4) Flip release lever up. To exit manual mode, reverse the above steps.
  • Page 11 The following section is instructions on mounting your gate opener. Your gate can be mounted one of two ways: Pull-To-Open: With the gate opener on the inside of the property, the gate will swing in towards the property. The gate opener will be extended in the gate’s closed position and as the opener retracts it PULLS the gate open.
  • Page 12 IMPORTANT: Determining Correct Setback PULL TO OPEN - Standard operation. This means the gate operator is mounted on the inside of the property and pulls your gate in towards the property. There are 4 factors to keep in mind when finding the setback mounting: 1) The (A) measurement is perpendicular from the gate in the CLOSED position.

  • Page 13: Installation Of Operator-Pull To Open

    Installation of Operator—Pull-to-Open 1. Find the proper set back for your operator (from previous page). Do this by holding the bottom “L” shaped bracket against the post. Marking its horizontal positioning on the post using a vertical line up from the middle of the bracket.
  • Page 14 5. Temporarily position the gate side mounting bracket. (horizontal position does not matter, vertical position on the gate is the position you are matching to the post bracket.) Position your assembled gate mounting along the previouslydrawn vertical line and level the angled piece with the horizontal piece of the gate mounting bracket using a level.
  • Page 15 9. Extend the operator arm so the measurement between the center of the pivot hole on the rear bracket and the center of the pivot hole in the front mounting measures 51 1/4 inches (63 inches for L-series). After finding the measurement relock your operator arm.
  • Page 16 Close the gate leaf. With the operator attached on the post side, move the end of the arm to the gate and, keeping the gate operator in a perfectly horizontal position, determine the gate mounting position. The arm should already be in it’s full closed length that was determined in step 9 Attach the gate mounting bracket using carriage bolts, nuts, and washers.
  • Page 17 IMPORTANT: Determining Correct Setback PUSH TO OPEN - This operation is commonly used if you driveway slopes up after the gate, preventing it from swinging in. This means the gate operator is mounted on the inside of the property and pushes your gate out away from the property.

  • Page 18: Installation Of Operator-Push To Open

    Installation of Operator—Push-to-Open 1. Find the proper set back for your operator (from previous page). Do this by holding the bottom “L” shaped bracket against the post. Marking its horizontal positioning on the post using a vertical line up from the middle of the bracket. Also mark your angled bracket for posi-tioning on the “L”...
  • Page 19 5. Temporarily position the gate side mounting bracket. (horizontal position does not matter, vertical position on the gate is the position you are matching to the post bracket.) Position your assem-bled gate mounting along the previously drawn vertical line and level the angled piece with the horizontal piece of the gate mounting bracket using a level.
  • Page 20 9. Retract the operator arm so the measurement between the center of the pivot hole on the rear bracket and the center of the pivot hole in the front mounting measures 36 inches (41 inches for L-series). After finding the measurement relock your operator arm.
  • Page 21 12. Close the gate leaf. With the operator attached on the post side, move the end of the arm to the gate and, keeping the gate operator in a perfectly horizontal position, determine the gate mounting position. The arm should already be in it’s full closed length that was determined in step 9.

  • Page 22: Easy Wiring Under Driveway

    Easy Wiring Under Driveway This portion of the manual will explain how to create an easy conduit for the wires for dual gates. This is what you would need to get started: - Narrow shovel. - ¾’ water pipe no more that 5’ in length (you would need a total number of pipes that would equal your driveway width plus 1’) - ¾’...

  • Page 23: For Your Convenience

    For Your Convenience The green terminal strips on the control board are easily removed for wiring. Simply pull straight out on the terminal strip to remove it from the board. It will slide right off. Slide it back on when you are finished with your wiring connections. Be sure you are placing your wires in the terminal block correctly.
  • Page 24 Wiring the Operator Arm(s) Attaching Arm Cover 1. Remove top cover. 2. Run the 5 Conductor wire through the cable gland and tighten the cable gland to squeeze the wire. Attach wires as indicated using thicker wires for motor installation. 3.
  • Page 25 Wiring the Operator Arm(s) For a dual gate, use the provided wire to connect the secondary motor to the control board Pull to Open (Opening in towards property) It is important to choose the correct operation type...
  • Page 26 Wiring the Operator Arm(s) for Pull to Open 1. Locate the wiring terminal board on the bottom of the operator arm(s). 2. Wire the operator arms according to the diagram below. NOTE: 1 indicates primary arm or Single operator connections, 2 indicates secondary arm if applicable and is not used in single gate installations.
  • Page 27 Wiring the Operator Arm(s) For a dual gate, use the provided wire to connect the secondary motor to the control board. Push to Open (Opening out towards the street) It is important to choose the correct operation type...
  • Page 28 Wiring the Operator Arm(s) for Push To Open 1. Locate the wiring terminal board on the bottom of the operator arm(s). 2. Wire the operator arms according to the diagram below. Wiring Connections for Operator Arm Power. Position Arm to board Terminal Board Board Connection...

  • Page 29: Temporary Safety Jumpers And Dip Switch Settings

    Temporary Safety Jumpers and Dip Switch Settings If you are not using a safety device like a Photo jumped to GND photo eye or safety loop the Photocell terminal must re-main jumped to the GND terminal. Dip Switches—To change any dip switches, you must turn the power off before changing the setting.

  • Page 30: Power

    Power The Estate Swing E-S 500 comes with 1) 24V transformer. The transformer supplied has 2 screw terminals to connect to. You may locate the transformer up to 200’ away from the control board using 16 gauge, 2 conductor stranded direct burial low voltage wire. Do not use solid core wire.

  • Page 31: Limit Switches

    Fine Tuning Limit Switches - Pull-to-Open Understanding the limit switches The stroke length is the distance between both limit switches. In- creasing the stroke length will make your operator open further or close further. Decreasing the stroke length will make your operator open less or close less.
  • Page 32 Programming Limit Switches - Pull-to-Open 1.Temporarily install gate opener arm upside down. 2.Press and hold the SET button until PL shows on the display (about 3 seconds) 3.Press and release BUTTTON1 and the display will change to O1 (Open limit, Motor 1) 4.Manually release the gate (motor 1 gate for dual gate opener) and move the gate to the desired open position.
  • Page 33 Programming Limit Switches - Push-to-Open 1.Temporarily install gate opener upside down. 2.Press and hold the SET button until PL shows on the display (about 3 seconds) 3.Press and release BUTTTON1 and the display will change to O1 (Open limit, Motor 1) 4.Manually release the gate (motor 1 gate for dual gate opener) and move the gate to the desired open position.
  • Page 34 First Run This is our recommended procedure to run the gate for the first time. PUSH 1 or PUSH 2 to increase or decrease the parameter. Then press SET button to move to the next parameter. 1. Press SET button to begin. 2.
  • Page 35 Operating Parameters Customization 1. LED shows P1: P1 is for setting your run time. The run time exists to allow to have the P2 slow down setting. This should always be set at least 5 seconds longer than it takes to open and close.
  • Page 36 Estate Swing 433 Plug-in Receiver 1. With the red plug already inside the control box, run the grey receiver wire out of the box through one of the water tight connections. DO NOT PERFORM THIS STEP WITH THE RED PLUG ATTACHED TO THE CONTROL BOARD.
  • Page 37 Estate Swing 433 Plug-in Receiver (cont.) 5. Plug the red clip inside the control box into the control board. The groove in the red clips should snap into the guide on the 5 prong connector. 6. The red power light should come on the receiver.
  • Page 38 Maintenance Lubricate the rear pivot and front pivot of the bracket. Lubricate the gate hinges about every 3 months, and also check for levelness of gate.

  • Page 39: Accessories

    Troubleshooting If the gate opener will not move but the board is counting the run time: • Check the F1 fuse for the primary arm (right hand fuse) and the F2 fuse for the secondary arm (center fuse). If the gate opener moves a few inches or feet and stops or reverses directions: •...

  • Page 40: Troubleshooting

    Troubleshooting The gate opener is moving past a limit switch or switches: Press and hold SET to enter PL mode. Use BUTTON1 to display the limit switch that is the issue, O1, C1, O2, C2. Manually move the gate opener from fully retracted to fully extend, listen for a BEEPING. If BEEPING occurs, stop the piston at the beeping, if this is not your desired position for open or closed then adjust the limit switch.
  • Page 41 This manual is for circuit boards manufactured after 4/15/15. If you have a previous versions of the circuit board an updated logic chip can be purchased and installed to make the board operate like the instructions. Please contact your Estate Swing dealer. During Limit Programming if BEEPING is not sounding when moving limit switch:...
  • Page 42 If you call in for technical support or warranty support: Before any control boar d or motor will be permitted to be sent in for testing or warranty you will be required to e-mail digital photos to the technician. This is done in your best interest to save unnecessary shipping expenses and time lost. Many times we can come up with solutions to issues by seeing pictures that relay information that is impossible to relay through a phone conversation.

  • Page 43: Control Board Overview

    Control Board Overview CAUTION! Do not r un 110V AC power direct to the boar d. This will cause permanent damage to both boards and void your warranty. Caution! Gate Opener reactions to signals: PUSH1 and Receiver (PUSH 1 terminal, PUSH 1 button, 5 Prong Receiver): Details: •...
  • Page 44 Control Board Overview CAUTION! Do not r un 110V AC power direct to the boar d. This will cause permanent damage to both boards and void your warranty. Caution! Gate Opener reactions to signals: PUSH2 (PUSH 2 terminal and PUSH 2 button): Details: •...
  • Page 45 Control Board Overview Light: Sends pulses of 24VDC only while gate is running, and whether it is open or closed. Motor 1: L1-1, L1-2 = 24VDC power to single motor or primary motor L2-1, L2-2 = 24VDC power to secondary motor Motor 2: OL1 = Open limit for single motor or primary Limit 1:...
  • Page 46 Control Board Overview CAUTION! Do not r un 110V AC power direct to the boar d. This will cause permanent damage to both boards and void your warranty. Caution! Display Indicators: Lights off on board & stand by / normal operation Lower right hand “dots”...

  • Page 47: Accessory Wiring

    Accessory Wiring The manufacturer instructions that come with your accessory should have markings for wires or terminals to connect to the gate opener. Please look for terminals named below in the instructions for the accessory. Keypads, Receivers: Normally Open (NO) or Input (INP) or Relay of entry device = COM ter minal (to r ight of PUSH1) of PUSH block on gate opener control board.
  • Page 48 Accessory Wiring Photo Eye, Safety Edge, Safety Loop: Normally Closed (NC) of safety device = Photo ter minal of PHOTO block on gate opener contr ol boar d. Common (COM) or Ground (GND) of safety device = GND ter minal of PHOTO block on gate opener con-trol board.
