Estate Swing E-S 1000H Series Instruction Manual

Vehicular gate opener (or system)
Hide thumbs Also See for E-S 1000H Series:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction Manual
EstateSwing.com
Plug-in Option
E-S 1000H Series
INSTRUCTION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E-S 1000H Series and is the answer not in the manual?

Questions and answers

Related Manuals for Estate Swing E-S 1000H Series

Summary of Contents for Estate Swing E-S 1000H Series

  • Page 1 EstateSwing.com Plug-in Option E-S 1000H Series INSTRUCTION MANUAL...
  • Page 2 Estate Swing Summary of Functions The Estate Swing is only to be used for vehicular swing gates in a Class I setting. Class I: A vehicular gate opener (or system) intended for use in a home of one-to-four single family dwelling, or a garage or parking area associ- ated therewith.

  • Page 3: Table Of Contents

    The table of contents are listed to assist you locating a desired section. We do however strongly suggest studying every page of the instruction manual before attempting installation. Section 1: Review of Specifications, Warnings, and Tools Specifications of the Estate Swing and Components Parts List System Overview & Preliminary Checks...

  • Page 4: Section 1: Review Of Specifications, Warnings, And Tools

    Section 1: Review of Specifications, Warnings, and Tools E-S 1000H Series Instruction Manual...

  • Page 6: Specifications

    The above chart represents the maximum weight and length combinations that this gate opener can handle. The lengths and weights are either for a single gate or for a single leaf of a dual gate. E-S 1000H Series Instruction Manual...

  • Page 7: Parts List

    1 - 5/16”x 1 3/8” Hex bolt, washer, nut 2 - 3/8”x 2” Carriage bolt, washers, nut 2 - 3/8”x 2” Carriage bolt, washers, nut 1 - 1/4” x 2” Hex bolt, washers, nut 1 - 1/4” x 2” Hex bolt, washers, nut E-S 1000H Series Instruction Manual...
  • Page 8 Photo sensors and a flashing light indicating gate movement is recommend- ed for safety purposes. 1,2 Estate Swing Operator • 3 Photocells (not included) • 4 Control board • 5 N/A • 6 Push but- ton opening device (not included) • 7 Receiver extension (not included)• 8 12Vdc flashing lamp (not included) •...

  • Page 9: Tools Needed For Installation

    Other items may be needed prior to commencing installation. Bolded items are necessary to all applications. • Positive post, bracket or door stop. Although the Estate Swing 1000 features built in limit switches it is highly rec- ommended to have positive stops.

  • Page 10: Section 2: Installation Of Mounting Brackets

    Section 2: Installation of Mounting Brackets E-S 1000H Series Instruction Manual...

  • Page 12: Manual Operation

    To Manually Change Position of Piston: 1) Remove pin as seen below. 2) The shaft can now be turned to open and close manually. 3) Replace pin to exit manual operation. E-S 1000H Series Instruction Manual...
  • Page 13 This means the gate operator is mounted on the inside of the property and pulls your gate in towards the property. If you are going to use push to open operation “X” out the next 3 pages and use the push to open section instructions. E-S 1000H Series Instruction Manual...
  • Page 14 To determine the position of the gate mounting bracket the right: (above is for the post mounting bracket) refer to step 13 in 6” 8½” 110° the section “Installation of operator” 7 ½” 9” 16 ½ 100° 9 ½” 9 ½” 90° E-S 1000H Series Instruction Manual...

  • Page 15: Installation Of Operator-Pull To Open

    Using the template, mark the boomerang bracket for cutting. [See Fig. 2] 4) Cut off the excess length (if any) of the boomerang bracket using a sawzall or hack- saw. Alternate Mounting Option E-S 1000H Series Instruction Manual...
  • Page 16 Mark then drill and attach the bracket using 3/8” carriage bolts. [See Fig. 4] Check “L” shaped bracket for levelness before putting in the second bolt. Fig 4 Continue on next page. E-S 1000H Series Instruction Manual...
  • Page 17 Fig 6 using a 5/16” drill bit in an area behind the first hole. Secure the hole with a 5/16” bolt and the provided nuts and lock washers. [See Fig. 6] Continue on next page. E-S 1000H Series Instruction Manual...
  • Page 18 15) To ensure that the gate mounting brack- et is leveled, secure one side of the bracket, check for levelness, and secure the other side with provided carriage bolts, nuts, and washers. [See Fig. 8] Fig 8 E-S 1000H Series Instruction Manual...
  • Page 19 This operation is commonly used if your driveway slopes up after the gate, prevent- ing it from swinging in. This means the gate operator is mounted on the inside of the property and pushes your gate out away from the property. E-S 1000H Series Instruction Manual...
  • Page 20 2 inches away from the 7 ½” 9” 16 ½ 100° gate in both the open and closed position. (variations significantly reduces the length and 9 ½” 9 ½” 90° weight capacity of the operator) E-S 1000H Series Instruction Manual...

  • Page 21: Installation Of Operator-Push To Open

    Using the template, mark the boomerang bracket for cutting. [See Fig. 2] 4) Cut off the excess length (if any) of the boomerang bracket using a sawzall or hack- saw. Alternate Mounting Option 2.10 E-S 1000H Series Instruction Manual...
  • Page 22 Mark then drill and at- tach the bracket using 3/8” carriage bolts. [See Fig. 4] Check “L” shaped bracket for levelness before putting in the second bolt. Fig 4 Continue on next page. 2.11 E-S 1000H Series Instruction Manual...
  • Page 23 5/16” drill bit in an area behind the first hole. Secure the hole with a 5/16” bolt Fig 6 and the provided nuts and lock washers. [See Fig. 6] Continue on next page. 2.12 E-S 1000H Series Instruction Manual...
  • Page 24 15) To ensure that the gate mounting bracket is leveled, secure one side of the bracket, check for levelness, and secure the other side with provided carriage bolts, nuts, and washers. [See Fig. 8] Fig 8 2.13 E-S 1000H Series Instruction Manual...
  • Page 25 Section 3: Gate Operator Mounting, Wiring Motors & Power E-S 1000H Series Instruction Manual...

  • Page 27: Mounting Gate Operator(S) & Finding Limits

    4) Temporarily secure the front of the arm with a clevis pin. You will be locating and setting the limits in the next page. E-S 1000H Series Instruction Manual...
  • Page 28 7) Move the other limit switch on the bot- tom to line up with the washer. Once you set the limits, secure the front side of the gate operator with the clevis pin and the cotter pin. E-S 1000H Series Instruction Manual...

  • Page 29: Control Box & Running Wires

    TIP: If junction box is located in a high mois- 8) Install and secure cover. ture area, apply petroleum jelly on to the See next page for instructions on running wire under terminal block to protect from moisture. the driveway. E-S 1000H Series Instruction Manual...

  • Page 30: Easy Wiring Under Driveway

    6 inches of pipe is sticking out from under the driveway. On the opposite side of the drive- way look for a wet spot or water bubbling up, dig to find the end of the pipe. E-S 1000H Series Instruction Manual...
  • Page 31 The terminals come closed. Be sure not to mis- take this for open and insert the wires below the terminal clamp. This will lack the conductivity to complete the circuit. E-S 1000H Series Instruction Manual...
  • Page 32 Wiring the Operator Arm(s) For a dual gate use the provided wire to connect the secondary motor to the control board. Pull to Open (Opening out towards property) It is important to choose the correct type operation type E-S 1000H Series Instruction Manual...
  • Page 33 For a dual gate use the provided wire to connect the secondary motor to the control board. Push to Open (Opening out towards the street) It is important to choose the correct type operation type E-S 1000H Series Instruction Manual...

  • Page 34: Temporary Safety Jumpers & Dip Switch Settings

    1 OFF. If the dip switch is set to on, the gate will au- to-reclose after turning it on without any intentional activation on your part. E-S 1000H Series Instruction Manual...

  • Page 35: Power

    Power The only power connected to the Estate Swing E-S1000H control board will be the battery. Important: Please respect polarity when attaching the battery terminals. Do not cross wires. Allow a minimum of 4’ of wire between the charge board and the transformer for this option.

  • Page 36: Section 4: Start Up And Operation

    Section 4: Start Up and Operation E-S 1000H Series Instruction Manual...

  • Page 38: First Run

    Re-attach gate opener to the gate bracket. Activate using Push 1 button (as shown above) The gate should run open. Press Push 1 again and it should run closed. The gate is now set up for regular use. E-S 1000H Series Instruction Manual...

  • Page 39: Determine Run Time

    Record your run time below. Actual Run Time: _____________________________ Note: The above example is for Pull-To-Open operation. If you are installing your gate opener as Push-To-Open then the open limit will be reverse of the above. E-S 1000H Series Instruction Manual...

  • Page 40: Operating Parameters Customization

    6. LED shows P6: P6 is the delay for automatic re-close from the open position – this option needs to be turned on using the dip switch on the board. The options are 0-99 seconds. E-S 1000H Series Instruction Manual...

  • Page 41: 433 Plug-In Receiver

    Please note that you will find a factory in- stalled jumper wire connected on the receiver. Leave this jumper wire in place. One of the terminals that has the jumper wire will have the White wire add- ed to the terminal. E-S 1000H Series Instruction Manual...
  • Page 42 DO NOT mount the receiver anyplace that water may access it from another angle. For ex- ample: Do not mount near sprinklers. Do not mount the receiver horizontally. Do not mount the receiver near a flat surface where water could splash upwards. E-S 1000H Series Instruction Manual...
  • Page 43 Section 5: Maintenance, Troubleshooting & Accessories E-S 1000H Series Instruction Manual...

  • Page 45: Maintenance

    Maintenance 1) Lubricate the rear pivot and front pivot of the bracket. 2) Lubricate the gate hinges about every 3 months and also check for levelness of gate. E-S 1000H Series Instruction Manual...

  • Page 46: Troubleshooting

    • If you are not using safety devices the safety jumpers are in place. If PH is on display it is an issue with the safety jumper or a device in the safety terminals. Continues on next page. E-S 1000H Series Instruction Manual...
  • Page 47 • For dual gates check that the delay between leafs is 2 or above. If both limits are triggered simultaneously there is a chance a limit could be missed. E-S 1000H Series Instruction Manual...
  • Page 48 • Set the #2 dip switch to the off position and run the gate as a single. Swap motor two for mo- tor one and run the unit as a single. This will determine if the problem is the control board or one of the arms. E-S 1000H Series Instruction Manual...
  • Page 49 Check the gate itself for any changes in levelness and make sure the hinges are lubricated  properly. Gate moves slower than normal: Check the battery voltage. Proper voltage should be between 12.5 - 13.8 and drop no  more than a quarter of a volt under load. E-S 1000H Series Instruction Manual...
  • Page 50 Many times we can come up with solutions to issues by seeing pictures that relay information that is impossible to relay through a phone conversation. Below are examples of control board pictures and motor pictures that we will be looking for: Pictures shown are actual customer photos E-S 1000H Series Instruction Manual...

  • Page 51: Control Board Overview

    6. When stopped mid cycle - momentary contact will open the gate. 7. When open with auto-reclose off - momentary contact will have no effect. 8. When closing - momentary contact will re-open the gate. E-S 1000H Series Instruction Manual...
  • Page 52 6. When stopped mid cycle - momentary contact will open the gate. 7. When open with auto-reclose off - momentary contact will have no effect. 8. When closing - momentary contact will re-open the gate. E-S 1000H Series Instruction Manual...
  • Page 53 5. When closing - momentary contact will re-open the gate. PUSH 1 and PUSH 2 – these terminals can hold as many normally open connections as needed, they will be wired in parallel. They are used for keypads, push buttons, universal receivers, etc. E-S 1000H Series Instruction Manual...
  • Page 54 Solenoid lock output - 12VDC (4 Amp max) A = Positive B = Negative Fuses: (2) F1 = 8A 250V, protects power to motors, fused individually F2 = 2A 250V, protects power to accessory 12V terminals E-S 1000H Series Instruction Manual...
  • Page 55 At this point no accessories or remotes will be able to activate the gate opener until the gate opener is reset by disconnecting pri- mary power battery. 5.10 E-S 1000H Series Instruction Manual...
  • Page 56 12V Power positive (+) or (12V) or (PWR) of exit device = +12V terminal of PHOTO block on  gate opener control board. 12V Power Negative (-) or (GND) or (PWR) or Shield wire of exit device = GND terminal of  PHOTO block on gate opener control board. E-S 1000H Series Instruction Manual...
  • Page 57 Connect positive lead of the power supply directly to the positive lead of the mag lock. Connect negative lead of the power supply to the N/C terminal of the relay. Connect the COM terminal of the relay to the negative lead of the mag lock. E-S 1000H Series Instruction Manual...
