Terex Genie Z-45 FE Service And Repair Manual page 94

Service and Repair Manual
Control System Fault Codes
Control System Fault Codes
Error Source
ID Component
Wall Powered
135 Charger Error Codes
(continued)
Pump/Generator
136
Motor Controller
84
Error Type
ID Name
29 CAN Bus error CANbus network error.
COMM battery
30 module CANbus battery module error
error
The Vref for the
ADC
31 measurements Internal charger error.
has triggered
an alarm
CAN Bus
32 CANbus heartbeat error.
heartbeat error
Battery Battery temperature sensor is required
36 Temperature by charge profile (battery temperature
Sensor Error compensated algorithm) by it is not installed.
CANOpen
37 reprogramming n/a
failed
Stalled Cooling Fan will not turn when commanded, rotor must
38
Fan Motor be locked
No CAN
0 No Response
communication
12..9 Curtis Fault Same as RR motor
9 Code controller
®
Z -45 DC • Z
Cause Effect
Hydraulic Functions
disabled
Same as RR motor
controller
®
-45 FE
July 2020
Solution
Check the physical
CAN connector,
electrical bus
conditions & other
CAN
modules for correct
function. For
example, check
termination
resistance is
approximately 60
ohms.
Check the CANbus
battery module
for correct functioning.
Remove AC and
battery for minimum
30 seconds & retry
charger.
Check the networked
CANbus device(s) for
correct functioning.
Check if sensor
is connected
correctly if alarm is
shown or ensure
thecharge profile
installed does not
require temperature
compensation.
Re-try CANOpen
download or
reprogram
using the USB
Fan is obstructed,
please inspect the fan
and clear the blockage
48V on C34-1
(R45GEN GR/WH)
Same as RR motor
controller
Part No. 1297714GT
