Terex Genie Z-45 FE Service And Repair Manual page 91

July 2020
Control System Fault Codes
Error Source
ID Component
Wall Powered
135 Charger Error Codes
(continued)
Part No. 1297714GT
Control System Fault Codes
Error Type
ID Name
Battery Battery could not be trickle charged up to the
4
defective minimum voltage.
Safety limit exceeded. Possible causes: Poor
battery health. Very deeply discharged battery.
Ah Limit
7 Poorly connected battery.
Exceeded
High parasitic loads on battery
while charging.
Battery
temperature
8 Could be battery temperature sensor error.
out of range
error
Charger is
disabled by
11
external
command
Reverse
12 Battery is connected the wrong way around.
polarity error
Z ® -45 DC • Z
Cause Effect
® -45 FE
Service and Repair Manual
Solution
*Check for shorted or
damaged cells
*Replace battery pack
*Check DC
connections
(This error will
automatically clear
once the charger is
reset)
*Replace battery pack
*Check DC
connections
*Disconnect parasitic
loads
(This error will
automatically clear
once the charger is
reset by cycling DC.)
*Check temperature
sensor and
connections
*Reset charger
(This error will
automatically clear
once the condition has
been corrected.)
Check the battery
connections.
(This error will
automatically clear
once the condition has
been corrected.)
81
