DEMO MANUAL DC1705A
PARTS LIST
ITEM QTY REFERENCE
DC1705A General BOM
1 1 CI1
2 1 CI2
3 1 CP
4 4 C1, C8, C9, C18
5 2 C2, C10
6 2 C6, C11
7 4 C7, C12, C15,
C19
8 C13, C14, C17,
C22, C23,
8 C24, C25, C26
9 1 C16
10 2 C20, C21
11 1 D1
12 4 E1, E2, E5, E8
13 1 E3
14 1 JP1
15 1 XJP1
16 4 J1, J3, J4, J5
17 1 J2
18 2 L1, L2
19 1 RZ
20 1 R1
21 1 R3
22 1 R4
23 4 R5, R6, R7, R13
24 2 R8, R9
25 3 R10, R11, R12
26 2 U2, U3
27 1 U4
28 4 4 Corners
DC1705A-A
1 1
2 1 U1
DC1705A-B
1 1
2 1 U1
DC1705A-C
1 1
2 1 U1
6
PART DESCRIPTION
Capacitor, X7R 0.022μF 50V 5% 0603
Capacitor, COG 6800pF 50V 5% 0805
Capacitor, COG 2700pF 50V 5% 0603
Capacitor, X7R, 1μF , 16V, 10%, 0805
Capacitor, Tantalum, 330μF , 10V, 10%, 7343
Capacitor, X7R, 470pF , 50V, 10%, 0402
Capacitor, X7R, 0.01μF , 16V, 10%, 0402
Capacitor, X5R, 0.1μF , 10V, 10%, 0402
Capacitor, X7R, 2.2μF , 16V, 10%, 0805
Capacitor, NPO, 100pF , 50V, 5%, 0402
LED, Red
Jack, Banana
Turret, Testpoint, 2501
Headers, 3 Pins 2mm Ctrs.
Shunt, 2mm Ctrs.
Connector, SMA 50Ω EDGE-LAUNCH
Connector, Header, 14-Pin, 2mm
Inductor, Chip, 68nH, ±5%, 0402
Resistor, Chip, 453 1/10W 1% 0603
Resistor, Chip, 51.1Ω, 1/16W, 1% 0402
Resistor, Chip, 330Ω, 1/16W, 1% 0402
Resistor, Chip, 15Ω, 1/16W, 1% 0402
Resistor, Chip, 200k, 1/16W, 1% 0402
Resistor, Chip, 4.99k, 1/16W, 1% 0402
Resistor, Chip, 100Ω 1/16W, 5%, 0402
IC, Dual Buffer SC-70 6-Lead
IC, Dual Transceiver SC-70 6-Lead
Standoff, Nylon, 0.5, 1/2"
DC1705A General BOM
IC Synthesizer QFN-28 4mm × 5mm
DC1705A General BOM
IC Synthesizer QFN-28 4mm × 5mm
DC1705A General BOM
IC Synthesizer QFN-28 4mm × 5mm
MANUFACTURER/PART NUMBER
AVX 06035C223JAT2A
Murata GRM2195C1H682JA01D
Murata GRM1885C1H272JA01D
TDK, C2012X7R1C105K
AVX, TPME337K010R0035
AVX, 04025C471KAT2A
AVX, 0402YC103KAT2A
TDK, C1005X5R1A104K
TDK, C2012X7R1C225K
TDK, C1005C0G1H101J
Panasonic, LN1251CTR
Keystone, 575-4
Mill-Max, 2501-2-00-80-00-00-07-0
Samtec TMM-103-02-L-S
Samtec 2SN-BK-G
E. F . Johnson, 142-0701-851
Molex, 87831-1420
Coilcraft, 0402 HPH-68NXJL
NIC, NRC06F4530TRF
NIC, NRC04F51R1TRF
NIC, NRC04F3300TRF
NIC, NRC04F15R0TRF
NIC, NRC04F2003TRF
NIC, NRC04F4991TRF
NIC, NRC04J101TRF
Fairchild Semi. NC7WZ17P6X
NXP 74LVC1T45GW
Keystone, 8833 (SNAP ON)
DC1705A
Linear Technology Corporation, LTC6946IUFD-1
DC1705A
Linear Technology Corporation, LTC6946IUFD-2
DC1705A
Linear Technology Corporation, LTC6946IUFD-3
dc1705afa
