- Page 1 50890 Waste Pump INSTRUCTION MANUAL...
-
Page 2: Waste Pump
Waste Pump Robust Single Diaphragm Design Features • Flexible installation • No filter required • Compact and simple design • Self-priming to 3m (9.5ft) • 12V and 24V variants • Dry running capability • Connections for 38mm (1-1/2") ports • Up to 19 lpm (5 US gpm) flow Specifications •... -
Page 3: Maintenance
Maintenance WARNING: Always disconnect pump from power supply. Check all electrical connections periodically, particularly in salt water areas. Corrosion can cause loss of performance or non-operation in extreme cases. The motor should be protected with a corrosion inhibiting spray and any rust should be removed and the motor repainted. Wiring Instructions •... - Page 4 Rotation of Pump Head Rotation of Ports...
-
Page 5: Exploded View
Exploded View Part Numbers Model Voltage Fuse Sizes 50890-1000 50890-1100 Service Kit SK890 Service Kit - Waste Pump Description Quantity in Kit Bracket Bush Clamp Bottom Clamp Top Con Rod Con Rod Plate Cover* Diaphragm* Hex Head Screw Hex Head Screw* Motor Assembly Screw Recessed Pan Head* Socket Head Screw... -
Page 6: Dimensional Drawing
Jabsco is a trademark of Xylem Inc. or one of its subsidiaries. © 2019 Xylem, Inc. 43000-0822 Rev. A 9/2019...
