A-Maize-Ing Heat NRP620-10 Owner's Manual

This wood heater needs periodic inspection and repair for proper operation. Consult the owner's manual for further information. It is against federal regulations to operate
RISK OF FIRE
DO NOT OPERATE WITH FLUE DRAFT EXCEEDING 0.050 IN WATER COLUMN
AS MEASURED BEFORE THE BAROMETRIC DAMPER.
DO NOT OPERATE WITH FUEL LOADING OR ASH REMOVAL DOORS OPEN.
HOT SURFACES
THE BURNER INSPECTION DOOR MAY BE HOT.
KEEP CHILDREN AWAY.
DO NOT TOUCH DURING OPERATION.
28" UNIT TO BACKWALL
9" UNIT TO SIDEWALL
FUEL: BIOMASS
ELECTRICAL: 120 V AC, 60 HZ, 12 A. CONNECT TO SEPARATE 15A FUSE.
MINIMUM DUCT SIZES: 196 SQUARE INCHES
THE HEAT EXCHANGER, FLUE PIPE, CHIMNEY, AND DRAFT CONTROL MUST BE IN GOOD CONDITION AND CLEANED REGULARLY TO REMOVE ACCUMULATED
CREOSOTE AND ASH. CLEAN AT THE END OF THE HEATING SEASON TO MINIMIZE CORROSION DURING SUMMER MONTHS.
DANGER: RISK OF EXPLOSION. DO NOT BURN GARBAGE, GASOLINE, DRAIN OIL OR OTHER FLAMMABLE LIQUIDS.
1. LET THE UNIT COOL
2. REMOVE THE ASHES WITH AN ASH VACUUM
3. FILL THE BURN POT WITH APPROVED BIOMASS FUEL
4. ADJUST THE THERMOSTAT TO A SETTING ABOVE THE ROOM
TEMPERATURE
CERTIFIED FOR SERIES CONNECTION TO THE OUTLET ONLY OF AN OIL FIRED, GAS FIRED, OR ELECTRIC FURNACE
MAY BE CONNECTED TO DUCTWORK THAT IS STILL CONNECTED TO
ANOTHER FURNACE.
MAY BE ADDED ONTO AN OIL, GAS, or ELECTRIC FURNACE HAVING AN INPUT
BETWEEN 34,000 to 120,000 Btu/hr AS SHOWN ON THE NAMEPLATE OF THE
OIL, GAS, or ELECTRIC FURNACE.
DO NOT CONNECT DUCTWORK SO A REVERSE FLOW IS POSSIBLE.
U.S. ENVIRONMENTAL PROTECTION AGENCY Certified to comply with 2017 particulate emissions standards using wood pellets. Not approved for sale after May 15, 2020
Conforms To: ASTM E2515-2011 & CSA B415.1-10
NATURE'S RENEWABLE PRODUCTS PO Box 500 899 S. PRAIRIE LANE MARSHFIELD MISSOURI 65706
this wood heater in a manner inconsistent with the operating instructions in the owner's manual.
THIS UNIT MAY BE INSTALLED ON A COMBUSTIBLE FLOOR
MINIMUM CLEARANCE TO COMBUSTIBLE CONSTRUCTION:
DO NOT USE CHEMICALS OR FLUIDS TO START THE FIRE.
TURN THE POWER SWITCH TO "OFF" IN THE EVENT OF A "RUN-AWAY" FIRE.
IF THE FIRE GOES OUT DUE TO AN EXTENDED POWER OUTAGE
WARNING
DO NOT STORE FUEL OR OTHER COMBUSTIBLE MATERIAL WITHIN MARKED
INSTALLATION CLEARANCES.
DO NOT CONNECT THIS UNIT TO A CHIMNEY FLUE SERVING ANOTHER
APPLIANCE.
CAUTION
THIS EQUIPMENT MAY ONLY BE INSTALLED BY QUALIFIED PERSONNEL
MAINTAIN COMBUSTION AIR SUPPLY TO BOTH FURNACES. AIR
STARVATION IS DANGEROUS. PROVIDE A FRESH AIR OPENING AT LEAST
2 2
2,000 mm (3 in ).
18" FLUE CONNECTOR TO BACKWALL
2" PLENUM TO CEILING.
DO NOT ALTER THIS EQUIPMENT IN ANY WAY.
LOAD FUEL CAREFULLY OR DAMAGE MAY RESULT.
INSPECT AND CLEAN FLUES AND CHIMNEY REGULARLY.
5. APPLY A GELLED FIRE STARTER APPROVED FOR BIOMASS
APPLIANCES AND LIGHT
6. SET SWITCH TO "START" UNTIL THE BIN AUGER ENGAGES
7. SET SWITCH TO "ON" AND ADJUST THE THERMOSTAT AS NEEDED
OPERATE THE OIL, GAS, ELECTRIC FURNACE PERIODICALLY TO ENSURE IT
WILL OPERATE SATISFACTORILY WHEN NEEDED.
DO NOT RELOCATE OR BYPASS ANY OF THE SAFETY CONTROLS IN THE
ORIGINAL FURNACE INSTALLATION.
DISCONNECT ELECTRIC POWER TO BOTH FURNACES BEFORE SERVICING.
Emissions: 0.458 lbs/MMBtu – Output (0.197 g/MJ of output)
