- Page 4 Lens Projection head Turning handle Swivel arm with socket Ventilation slots Housing Fading speed Mounting plate Fader Mounting plate release On/off...
- Page 5 Thank you for purchasing this high-quality product. GoboTopPlus is exclusively manufactured in Germany and meets the highest quality and safety standards. We are confident that you will be amazed by the crisp projections produced by this tiny but versatile projector. Please read these operating instructions first in order to use the system effectively and safely! Contents of package: - Halogen projector GoboTopPlus including lamp MR 16, 12V/50 W, 24°.
- Page 6 Warning Symbol This symbol indicates that you will be informed about risks that may lead to injury to persons or damage to property. Users must read and observe these directions strictly in order to operate the system safely. Information Symbol This symbol indicates that you will receive additional information that will help you use your system more effectively.
-
Page 7: Table Of Contents
Table of Contents How to use GoboTopPlus effectively Ambient light conditions Suitable projection surfaces Image sizes at increasing distances Installation Placement of unit Wall or ceiling mount using power cord and plug Wall or ceiling mount using insulating screw joints /spade connections Inserting the gobo and assembly General handling Adjusting focus... -
Page 8: How To Use Gobotopplus Effectively
How to use GoboTopPlus effectively Ambient light conditions The best and most brilliant image projections can be achieved in darkness or low ambient light. Daylight or direct sunlight are much brighter than artificial lighting and will outshine any projected image. Avoid directing spotlights or lamps at the projection surface for optimal results. -
Page 9: Image Sizes At Increasing Distances
Image sizes at increasing distances As a rule, image size increases with distance, whereas contrast and brightness decrease. In normal ambient light, GoboTopPlus displays images over short projection distances, from 0.5–1.5 meter. Greater projection distances can be achieved in low ambient light or darkness. Image size can only be adjusted by varying the distance between projector and projection surface. -
Page 10: Installation
Installation Placement of unit Choose a suitable place for GoboTopPlus and plug it into an outlet. Now the system is ready for use. Ceiling mount Wall mount... - Page 11 Please note: When GoboTopPlus is mounted on the ceiling, vertical projections on the floor can only be created using the optional deflection mirror , otherwise the system may overheat. The specially designed deflection mirror can be ordered with part no.: 01023520.
-
Page 12: Wall Or Ceiling Mount Using Power Cord And Plug
Wall or ceiling mount using power cord and plug 1. Before mounting GoboTopPlus, find the best position for image projection. Switch the system on and arrange the projected image as accurately as possible. 2. Mark the position on the wall or ceiling. 3. -
Page 14: Wall Or Ceiling Mount Using Insulating Screw Joints/Spade Connections
Wall or ceiling mount using insulating screw joints/spade connections Please note that the following articles pertains to the previous chapter “wall and ceiling mount, using power cord and plug”. Unplug the system. Make sure that the providing circuit is volt-free. 1. -
Page 16: Inserting The Gobo And Assembly
Inserting the gobo and assembly Avoid touching the hot projection head, lamp, socket and swivel arm when the system is in operation. Switch it off and let it cool down for at least 15 minutes before you handle accessories, gobo or lamp. 1. -
Page 18: General Handling
General handling Avoid touching the hot projection head, lamp, socket and swivel arm when the system is in operation. Switch it off and let it cool down for at least 15 minutes before you handle accessories, gobo or lamp. Adjusting the focus (see fig. page 15, Adjusting the fader. -
Page 19: Replacing The Lamp
Switch it off and let it cool down for at least 15 minutes before you handle accessories, gobo or lamp. Use only replacement lamps that are tested and approved by Derksen Lichttechnik. If you operate GoboTopPlus with an unsuitable lamp, the system will be damaged. -
Page 20: Safety Precautions
100°C. Wait approx. 15 minutes until the system has cooled down before you handle gobo, lamp, swivel arm or projection head. - Use only replacement lamps that are tested and approved by Derksen Lichttechnik. If you operate GoboTopPlus with an unsuitable lamp, the system will be damaged. - Page 21 - The system is designed to be used in normal room temperature. High temperatures or intense sunlight may cause damages. - Do not obstruct the airflow to the system. The housing and the ventilation slots must not be covered. - If the system is built into a closed wall, ceiling or cabinet, it must be sufficiently ventilated. - Do not install the system near liquids.
-
Page 22: Power Supply Precautions
Power supply precautions - The power cord must not be damaged! Avoid placing items on it. The power cord must not be bent, twisted or pinched. A damaged power cord may cause electric shock or fire and must be replaced immediately. - Make sure that the voltage current matches the system. -
Page 23: General Handling Precautions
General Handling Precautions - Only use original accessories made by Derksen Lichttechnik, which are specially designed to be used with GoboTopPlus. When using incompatible accessories from other manufacturers, injury to persons or damage to property may result. - Only insert glass or metal gobos. Never use other items such as colour slides or transparencies. -
Page 24: Transportation, Cleaning, Repair
Do not use any aggressive cleaners or thinners such as alcohol or benzene. Only use optical cleaning tissues for cleaning the lens and the image (glass or metal gobo). - Ask a qualified technician for repair and cleaning of the inner parts. Systems can be sent directly to Derksen Lichttechnik for maintenance and repair. -
Page 25: Technical Specifications
Technical Specifications Voltage type 230V 115V Black Part-no.: 09927620 Part-no.: 09927720 Silver Part-no.: 09927630 Part-no.: 09927730 Power consumption: 55VA 57VA Power consumption in standby mode: 3VA 3 VA Efficiency: cosø 0.95 cosø 0.98 Mains frequence range: 45–66Hz 45 –66Hz Fuse: 1A T(delay) 1.6A T(delay) Temperature fuse (built in):... -
Page 26: Warranty Conditions
Derksen. Warranty repair service is excluded, if the operating instructions were not observed. The defective system can be returned within the warranty period to your dealer or to Derksen Lichttechnik GmbH with a copy of the invoice and a brief description of the problem. - Page 28 Serviceadresse Service Contact Derksen Lichttechnik GmbH Sauerlandstraße 5 45889 Gelsenkirchen Germany T: +49 (0)2 09 /9 80 70-0 F: +49 (0)2 09 /9 80 70-60 info@derksen.de www.derksen.de...
