PREPARING AND OPERATING THE FLOOR MACHINE
PREPARTION OF MACHINE
•
Grab the handle and tilt the machine
backwards on its wheels (A).
•
Wheel machine to place of work and plug in
the power cord.
•
Put the accessories, brush or pad driver with
pad on the floor in front of the machine
•
Tilt the machine backwards and move it
over the brush or pad driver until the clutch
plate and drive star are vertically aligned.
Lower machine onto brush/pad driver.

OPERATION OF MACHINE:

•
Press the dead man switch (4) and briefly
press the brush motor trigger (2). The motor
starts.
•
If you raise the handle slightly upwards, the
machine moves to the right (D).

AFTER EACH USE:

•
Squeeze the handle adjustment lever (5)
and move the handle back into its vertical
position.
CLEANING with the solution tank
•
For cleaning floors, the floor-machine can
be equipped with the following accessories:
Scrub brush or pad driver with pad
o
Solution tank (13)
o
•
Attach tank to handle (14).
•
Slide the solution hose (12) onto the water
connector (16).
SHAMPOOING
•
For cleaning floors, the floor-machine can
be equipped with the following accessories:
Solution tank (13)
o
Shampoo brush or pad driver with
o
respective pad
Safety, Operations and Maintenance Manual for Floor Machines PowerDisc, R44-180, R44-Dual; Version 1.0
•
Squeeze the handle adjustment lever (5)
and lower the handle (7) to a comfortable
working position. Both arms should be
extended comfortably (C).
•
Align the machine horizontally over the
brush/pad driver, press the dead man switch
(4) and briefly press the brush motor trigger
(2).
•
The brush/pad driver automatically spins in
place.
•
If you lower the handle slightly, the machine
moves to the left (D).
•
If you keep the handle in its central position,
the machine works on the spot and can also
be moved straight forward or reverse
•
Then tilt the machine backwards onto its
wheels (9). Remove brush / pad holder by
rotating it clockwise.
•
Unplug the power cord (18) and wind it
around the handle (1) and cord wrap (8).
•
Fill the tank (13). Then attach the brush or
pad driver with pad.
•
Control the solution flow with the tank lever
(15) by pulling the lever (15) upwards.
•
Pick up the dirty solution with a wet/dry
vacuum or auto-scrubber.
•
The procedure is in principle the same as
described under "Cleaning with the solution
tank"
•
Start the machine with a dry shampoo brush
•
Meter a small amount of cleaning solution to
the brush until the bristles are saturated with
foam.
