CalibrtttiOIl-1Dl1 Service
OUTPUT SIGNALS
Equipmen t Required
1. Indicator mainframe
2 . Wide·band amplifier plug-in unit
3. Dual·trace amplif ier plug-in unit
4. Time-base plug·in unit
5, Time-mark generator
6. Two l a -inch 50 -ohm aNC cables (must be equal
length)
7 . Two 50-ohm BNC term inations
8 . Medium-frequency signal generator
BEFORE YOU BEGIN,
see
ADJUSTMENT LO CATIONS
in the Diagrams section.
Set·Up
In the ind icator mainframe, install t he 70 11 and
wide-band am plifier unit in the ve rtical plug-in compart-
me nts. Install the l ime·base unit in the B horizontal plug-in
compartment , Set the controls as follows :
TRI GGER
SLOPE
LEVE L
COUPLI NG
SOURCE
EVENTS STA AT TRI GGER
SLOPE
LEVE L
B SWEEP DELAY MODE
CQUNTMODE
FINE OELAY
+
Clockwise
AC
EXT
Clockwise
INDEPENDEN T
TI ME INT CLOCK
0.0
.J23 .
Check Front-Panel Delay Interval Output
a Connect the marker output of the t ime-mark gener·
ator to the EX T TRI G IN connector.
b. Set the time-mark generator for one·microsecond
markers
c. Connect the DL Y INTER VAL OUT connector to the
amplifier ·unit input.
d . Set the amplifier uni t for a calibrated deflection
factor o f 0 .5 volt/division.
e. Set the mainframe to select the am plifier unit for
display and as the internal trigger sou rce for the time-base
unit.
t.
Set the time·base unit fo r auto, internal triggering at
the sweep rate of 20 nanosecond/division,
g. Set the TRI GG ER LEVEL control to obtain a
display,
v h, CHECK - Displayed pulse amplitude is two divisions
or greater (delay interval pulse amplitude is one volt or
greater into SO-ohm load) .
V i. CHECK- Displayed waveform for 3 .5
to
four divi -
REV. B, AUG. 1915
sions (70 to 80 nanoseconds ) between t he 50%-amplitude
points of the rising and falling portions (D LY INTERVAL
OUT signal equal to generated time delay less 20 to 30
nanoseconds),
j. Set the COUNT MODE switch to EVENTS. Connect a
4QO·miilivoh, iour-megahertz signal from the medium·
frequency signal generator to the EVENTS START T RIG
I N connector,
k. Set the DE LAY TI ME OR EVENTS control for an
events-count readout of 0000002,
I. Set
the time·base uni t for a sweep rate of 200
nanoseconds/division .
m. Set the EVENTS START T RI GGER LEVEL control
to obtain a pulse display ,
..In. CHECK- Displayed waveform for 5 di visions be·
tween the 50%·amplitude points on the rising and falling
portion (DLY INTERVA L OUT signal equal to generated
events delay within 30 nanoseconds; one microsecond ±30
nanoseconds) .
o . Set the amplifier-unit deflection factor to obtain a
display amplitude of five or six divisions.
p. Set the t ime,base unit to start the sweep prior to the
rising portion of the waveform at a sweep rate of two
nanoseconds/division.
..Jq. CHECK- Displayed waveform for not more than
2.5 divisions between the 10%· and 9O%-amplitude poi nts
(tisetime into 50 ohms, five nanoseconds or less) ,
r. Set the time·base unit to start the sweep prior to the
falling portion of the waveform ,
4·19
